THIS ITEM FITS VARIOUS APPLICATIONS BY PART NUMBER. PLEASE CHECK YOUR PART NUMBER TO ENSURE FITMENT.
PRODUCT TYPE: HUB ASSEMBLY
ASSEMBLY/SINGLE: SINGLE
SPECIFICATIONS:
ABS SENSOR INCLUDED: YES
ABS SENSOR RING DIAMETER (IN): 2.008
ABS SENSOR RING DIAMETER (MM): 51
ABS SENSOR RING INCLUDED: YES
ABS SENSOR RING TYPE: TONE RING
BEARING TYPE: BALL
DRIVEN OR NON-DRIVEN: NON-DRIVEN
FLANGE BOLT SIZE (IN): 1.142
FLANGE BOLT SIZE (MM): 29
FLANGE BOLT THREAD SIZE: M12X1.5
FLANGE DIAMETER (INCH): 2.165
FLANGE OFFSET (INCH): 2.941
FLANGE SHAPE: CIRCULAR
GASKET OR SEAL INCLUDED: YES
GREASEABLE: YES
HUB CENTERBORE DIAMETER (IN): 3.937
HUB CENTERBORE DIAMETER (MM): 100
HUB DIAMETER (IN): 5.512
HUB PILOT DIAMETER (INCH): 2.399
LUG BOLT THREAD SIZE: 10.45
LUG BOLTS INCLUDED: 4
MATERIAL: CHROME STEEL
NEW OR REMANUFACTURED: NEW
NUMBER OF ABS SENSOR RING TEETH: 48
NUMBER OF BOLT HOLES: 4
NUMBER OF BOLTS TO KNUCKLE: 4
NUMBER OF FLANGE BOLTS INCLUDED: 4
NUMBER OF LUG BOLTS INCLUDED: 4
NUMBER OF LUGS: 4
NUMBER OF MOUNTING BOLTS TO KNUCKLE: 4
ROLL-FORMED: NO
TOTAL HUB DIAMETER (IN): 5.512
TOTAL HUB DIAMETER (MM): 140
TOTAL HUB HEIGHT (IN): 4.909
TOTAL HUB HEIGHT (MM): 124.7
REPLACES:
OTHER PART NUMBER: PT512019
SKF: BR930436
TIMKEN: 512019
AUTOPART INTERNATIONAL: 1411-45120
BCA: WE61021
BECK/ARNLEY: 051-6096
CENTRIC PARTS: 40644000E
MEVOTECH: H512019 H512184
MOOG HUB ASSEMBLIES: 512019
NAPA: PBR930436
APPLICATIONS:
GEO PRIZM (1993-1997)
TOYOTA COROLLA (1993-1995)
