⚠️ THIS IS A SIX VOLT STARTER:
• 6 VOLT, not 12 volt, read this before ordering
• The same Hyster models went to 12 volt from 1961
• A 12 volt truck will NOT use this unit
HYSTER LIFT TRUCK:
• Hyster S-60AP, Continental F-226, 1959 to 1960
• Hyster S-70AP, Continental F-226, 1959 to 1960
• Hyster S-80AP, Continental F-226, 1959 to 1960
• Hyster S-100AP, Continental F-244, 1959 to 1960
• Hyster UE-30P, Continental F-162, 1959 to 1960
• Hyster YE-40P, Continental F-162, 1959 to 1960
1961 AND LATER ARE TWELVE VOLT:
• The 1961 and 1962 S-100AP runs a 12 volt Delco, not this one
• Those units are Delco 1107204, 1107295, 1108423, Wilson 91-01-4025
• Ours is Wilson 91-01-4026, one digit away, and it is 6 volt
• Check the battery and the generator, not just the model number
HOW TO VERIFY FIT:
• Clockwise, right hand rotation viewed from the pinion end
• 9 tooth pinion, direct drive, closed nose cone
• Three bolt flange mount, grounded case, Delco 10MT family
• SIX VOLT, about 25.39 lb / 11.54 kg
DO NOT ORDER IF:
• Your truck runs a 12 volt system, this is the 6 volt unit
• Your mount has two bolt holes, this one has three
• You need a counterclockwise unit, this starter turns clockwise
CROSS REFERENCE:
• Delco Remy 1107198, 1108068
• Wilson 91014026, 91-01-4026
• Family Delco 10MT, 10MTE, 6 volt, direct drive
