New 16/2 Awg Marine Cable 100Ft Tinned Copper 2-Conductor Red Black White Round Compatible With

UNIVERSAL MARINE WIRE — 16/2 AWG MULTI-CONDUCTOR BOAT CABLE 100 FT SPOOL:

CABLE CONFIGURATION:
• 2 Conductors x 16 AWG Each (Red + Black ABYC Color-Coded Pair)
• White Round Outer PVC Jacket — UV and Chafe Resistant
• Class K Tinned-Copper Stranding (26 x 30)
• Nominal O.D. 0.313 Inch — Compact and Flexible
• 600 Volt Rated (Higher Voltage Rating Than Single-Conductor Primary Wire)
• 105°C Dry / 75°C Wet Temperature Rating
• UL Listed BC-5W2 Boat Cable per UL 1426

WHY USE 2-CONDUCTOR JACKETED CABLE vs SINGLE-CONDUCTOR WIRE:
• Pre-Paired Red + Black Conductors — Single Cable Run for Complete Circuit
• Outer Jacket Provides Chafe, UV, and Physical Damage Protection
• Easier Installation Through Bulkheads, Conduit, and Loom
• Higher 600V Voltage Rating vs 50V DC Primary Wire
• Cleaner Look for Visible Cable Runs
• Reduces Cable Clip and Tie-Wrap Count
• Internal ABYC Color Coding Maintained (Red Positive + Black Negative)

COMMON 16/2 MARINE BOAT CABLE APPLICATIONS:
• Bilge Pump Wiring (Most Common Use — Single Cable Run from Switch to Pump)
• Navigation Light Circuits (Bow, Stern, Anchor, Masthead Lights)
• Cabin Lighting Circuits
• Cockpit Accessory Wiring
• Marine Radio and Electronics Power Feeds
• Stereo Speaker Wiring (Speaker Run from Amplifier)
• 12V Cigarette Lighter and USB Outlet Wiring
• Anchor Light Wire (Mast or Pole-Mounted)
• Trim Tab Indicator Wiring
• Helm Gauge Feeds (Smaller Gauges)
• Livewell and Aerator Pump Wiring
• Stern and Transom Light Wire
• Deck Light Wiring
• Underwater Light Power Cable
• Bait Tank Pump Wiring
• Cabin Fan Wiring
• Marine Horn Wiring (Both Conductors)
• Wakeboard Tower Speaker Cable
• Spreader Light Wiring (Sailboats)
• Compass Light Cable Run

NOT RECOMMENDED FOR (USE LARGER GAUGE OR DIFFERENT CABLE TYPE):
• Main Battery Cables — Use Heavy Gauge Single-Conductor (8, 4, 2, 1/0 AWG)
• High-Current Loads Above ~10-15 Amps Continuous — Use 14/2 or 12/2 Cable
• Engine Starter Wiring — Use Single-Conductor Heavy Gauge
• Bonding/Safety Ground Applications — Use Single-Conductor Green Wire
• AC Shore Power Wiring — Use Triplex or Specific AC Marine Cable

COMPATIBLE VESSEL TYPES:
• All Powerboats — Center Console, Cuddy Cabin, Express Cruiser, Walk-Around
• All Sailboats — Day Sailers, Cruisers, Racing Yachts, Liveaboards
• Pontoon Boats and Houseboats
• Bass Boats and Bay Boats
• Personal Watercraft (PWC) Wiring Harness Repairs
• Outboard Motor Wiring Harness Extensions
• Sterndrive and Inboard Engine Compartment Wiring
• RV and Trailer Marine-Grade Multi-Conductor Wiring

STANDARDS COMPLIANCE:
• UL Listed UL 1426 Boat Cable Standard
• UL Listed BC-5W2 Boat Cable Classification
• ABYC E-11 Compliant (American Boat & Yacht Council)
• United States Coast Guard (USCG) Approved
• Made in USA

FITMENT NOTE:
Universal multi-conductor marine boat cable — fits any marine application requiring a 16/2 AWG paired DC circuit run. Not vehicle-specific. The internal red conductor follows ABYC E-11 designation for positive 12V; the black conductor follows ABYC traditional DC negative designation. For 14/2 step up (more current capacity), for 18/2 step down (smaller circuits). Single-conductor primary wire is preferred for branch circuits where multiple loads share a common return.
