New 14/3 Awg Marine Ac Cable 100Ft Tinned Copper 3-Conductor Black White Green Compatible With

UNIVERSAL MARINE WIRE — 14/3 AWG FLAT AC TRIPLEX BOAT CABLE 100 FT SPOOL:

THE 15A AC BRANCH CIRCUIT CABLE — STANDARD FOR CABIN OUTLETS:
Per ABYC E-8 marine AC standards and NEC 210.21, 14 AWG conductors are required for standard 15 amp AC branch circuits. This 14/3 flat triplex is the standard cable for cabin GFCI receptacles, cockpit outlets, stateroom outlets, salon AC outlets, and smaller AC accessory feeds on pleasure boats.

CABLE CONFIGURATION:
• 3 Conductors x 14 AWG Each (Black + White + Green ABYC E-8 AC Code)
• White FLAT Outer PVC Jacket — Low-Profile Triplex Construction
• Class K Type 3 Tinned-Copper Stranding (41 x 30, Extra-Flexible Marine Spec)
• Nominal O.D. 0.223 x 0.500 Inch — Compact Flat Profile
• 50V DC / 600V AC Voltage Rating
• 105°C Dry / 75°C Wet Temperature Rating
• AC Branch Circuit Rating: 15A Standard (ABYC E-8 / NEC 210.21)
• UL Listed BC-5W2 Boat Cable per UL 1426

ABYC E-8 AC COLOR CODE — IMPORTANT FUNCTIONAL DESIGNATION:
• BLACK = AC HOT / LIVE (Ungrounded Conductor)
• WHITE = AC NEUTRAL (Grounded Conductor)
• GREEN = AC SAFETY GROUND (Equipment Grounding Conductor)
Per ABYC E-11 / E-8, AC safety ground conductor must be sized to match supply ampacity. For 15A AC branch circuits, 14 AWG is the correct gauge.

WHEN TO USE 14/3 — 15A AC BRANCH CIRCUITS:
• 16/3 AC cable (15A — smaller round triplex) — B6W16T-30 round version
• 14/3 AC cable (THIS ITEM, 15A) — STANDARD branch circuits, flat profile
• 12/3 AC cable (20A branches) — galley appliances, dedicated outlets — B7W12T-30
• 10/3 AC cable (30A shore power) — L5-30R inlet to panel — B7W10T-30
• 8/3 / 6/3 AC cable (50A shore power) — L14-50R systems

COMMON 14/3 FLAT AC TRIPLEX MARINE APPLICATIONS:
• Standard 15A AC Branch Circuits (Cabin GFCI Receptacles)
• Cockpit GFCI AC Outlet Wiring
• Cabin Convenience Outlet Branches
• Stateroom AC Outlet Circuits
• Salon AC Outlet Circuits
• Head (Bathroom) GFCI Receptacle Circuits
• Smaller Battery Charger AC Input (10A Smart Chargers)
• Cabin AC Accessory Feeds (TVs, Fans, Smaller Appliances)
• Marine TV / AV Equipment AC Power
• Smaller AC Heater Feeds (Under 15A)
• Reading Light AC Circuits (Cabin)
• Marine LED Light AC Feeds (Where AC-Powered)
• Cabin Clock and Small Electronic Outlets
• Computer and Charging Station Outlets
• AC USB Charger Receptacle Circuits
• Inverter AC Output to Small Loads
• Cabin Galley Light AC Feed
• Engine Room AC Outlet (Service Outlet)
• Cockpit Spotlight AC Power (When AC-Powered)
• Marine Stereo AC Power (Where AC-Powered)
• Refrigerator AC Input (Smaller AC Refrigerators Under 15A)
• Cabin Branch Circuit from Distribution Panel

NOT RECOMMENDED FOR (USE LARGER GAUGE OR DIFFERENT CABLE):
• 20A AC Branch Circuits — Use 12/3 (B7W12T-30)
• 30A AC Shore Power Main — Use 10/3 Triplex (B7W10T-30)
• 50A AC Shore Power — Use 8/3 or 6/3 Triplex Cable
• Main AC Distribution Panel Feeds — Use Larger Gauge
• Heavy AC Loads Above ~15 Amps — Step Up to 12/3 or 10/3
• DC Circuits — Use 14/2 DC Cable (B7W14T-21 Red+Black)
• Bonding/DC Safety Ground — Use Single-Conductor Green Wire

COMPATIBLE VESSEL TYPES:
• All Pleasure Boats with AC Distribution Systems
• Cuddy Cabin and Express Cruiser Powerboats with AC Systems
• Sailboats with Auxiliary AC Systems and Inverters
• Pontoon Boats and Houseboats with 30A Shore Power
• Trawlers and Sportfish Boats with Cabin AC
• Sterndrive and Inboard Powered Cruisers
• Liveaboard Vessels with AC Branch Circuits
• RV and Trailer 15A AC Branch Circuits

STANDARDS COMPLIANCE:
• UL Listed UL 1426 Boat Cable Standard
• UL Listed BC-5W2 Boat Cable Classification
• ABYC E-8 Compliant (AC Electrical Systems on Boats)
• ABYC E-11 Compliant (American Boat & Yacht Council)
• United States Coast Guard (USCG) Approved
• Made in USA

FITMENT NOTE:
Universal 15A AC marine flat triplex cable — fits any marine application requiring 14/3 AWG black/white/green AC conductors at 15 amp branch circuit ampacity. Not vehicle-specific. Per ABYC E-8/NEC 210.21, 14 AWG is the correct gauge for 15A AC branch circuits. For 20A branches use 12/3 (B7W12T-30). For 30A shore power use 10/3 (B7W10T-30). For DC use see B7W14T-21 (14/2 red+black flat duplex). Black/white/green color coding is functional per ABYC E-8 — DO NOT use for DC circuits.
