OEM PART NUMBERS:
• Yamaha: 93306-30810-00 (Crankshaft Main Bearing — primary)
• Yamaha: 93306-00423-00 (Crankshaft Bearing — alternate)
• Yamaha: 93306-00431-00 (Crankshaft Bearing — alternate)
• Yamaha: 93306-20541-00 (Crankshaft Bearing — alternate)
• Yamaha: 93306-27803-00 (Crankshaft Bearing — alternate)
• Yamaha: 93306-00519-00 (Crankshaft Bearing — alternate)
• Yamaha: 93306-20481-00 (Crankshaft Bearing — alternate)
• Yamaha: 93310-84039-00 (Crankshaft Oil Seal — primary)
• Catalog Kit Reference: K053
• Used when installing new HR4079 crankshafts
SPECIFICATIONS:
• Type: Crankshaft Main Bearing and Oil Seal Kit
• Application: Bottom-End Rebuild / Crankshaft Replacement (Used When Installing New HR4079 Crankshafts)
• Engine Coverage: Yamaha 686cc 4-Stroke Single-Cylinder Liquid-Cooled SOHC Platform — Used by Raptor 700, Grizzly 700, Kodiak 700, Rhino 700, and Viking 700
• Engine Displacement: 686cc
• Bore × Stroke: 102mm × 84mm
• Engine Code: J420 / 1S3 / 2BG Family (Yamaha Internal)
• Year Range: Raptor 700 2006-2025 / Grizzly 700 2007-2025 / Rhino 700 2008-2013 / Viking 700 2014-2025 / Kodiak 700 2019-2025
• Cylinder Configuration: Single-Cylinder Inline 4-Stroke Liquid-Cooled SOHC 4-Valve
• Transmission: Manual 5-Speed with Reverse (Raptor) or Yamaha Ultramatic CVT with High/Low Range (Grizzly, Kodiak, Rhino, Viking)
• Fuel Delivery: Electronic Fuel Injection
• Lubrication: Wet Sump
• Kit Contents: 2x Crankshaft Main Bearings (Prelubed and Packaged with Waterproof Grease), 2x Crankshaft Oil Seals (Left and Right) with Sealing Lip
• Models Covered: Yamaha Raptor 700 / 700R / R / SE, Grizzly 700 / Hunter / SE, Kodiak 700 / Hunter / Hunting / SE, Rhino 700, Viking / Hunter / Ranch / SE
• Use: Compatible with Yamaha OEM and Hot Rods aftermarket HR4079 crankshafts
• Condition: New
APPLICATIONS:
• Yamaha Raptor 700 / 700R 4-Stroke 686cc Sport ATV (2006-2025)
• Yamaha Grizzly 700 / Hunter / SE 4-Stroke 686cc 4×4 Utility ATV (2007-2025)
• Yamaha Kodiak 700 / Hunter / Hunting / SE 4-Stroke 686cc 4×4 Utility ATV (2019-2025)
• Yamaha Rhino 700 4-Stroke 686cc Side-by-Side (2008-2013)
• Yamaha Viking 700 / Hunter / Ranch / SE 4-Stroke 686cc Side-by-Side (2014-2025)
• 20+ year Yamaha 686cc engine platform — one of the longest-running ATV/SxS engines in the industry
