OEM PART NUMBERS:
• General Pump: EP1313G8
• General Pump (Left Hand): EP1313G8L
• Pump Made Ready: PMREP1313G8
• With Unloader: EP1313G8U/IF
• Old PWP Number: APU-3489
SPECIFICATIONS:
• Type: Triplex Plunger Pump — Evolution (EP) Series
• Drive: Direct Drive — 1" Hollow Shaft with SAE J609B Gas Flange
• Bore: 0.512" (13mm) / Stroke: 0.512" (13mm)
• Max Flow: 4.0 GPM @ 3400 RPM
• Max Pressure: 4000 PSI
• GHP Required: 16.4 (Gas Horsepower)
• Max Inlet Pressure: 125 PSI
• Max Fluid Temperature: 165°F
• Crankcase Oil Capacity: 15 oz
• Inlet Port: 1/2" Threaded Female / Discharge Port: 3/8" Threaded Female
• Manifold: Forged Brass — Increases Working Pressure to 4000 PSI
• Plungers: Solid Ceramic with Dual Guide System and Guide Bushing
• Connecting Rods: Large, Lightweight for Maximum Life
• Seals: Dual Diameter Plunger Guide / Optimized Outlet Valves / Dual Lip Oil Seals
• Weight: 15 lbs / Dimensions: 9.5" x 9.5" x 6.45"
• Warranty: 5 Years Consumer / 5 Years Commercial
• Made in Italy — Interpump Group
• Condition: New
APPLICATIONS:
• Direct-Drive Gas-Powered Pressure Washers — 4000 PSI / 4.0 GPM @ 3400 RPM
• Fits 9.0-13.0 HP SAE Gas Engines via SAE J609B Flange
• Surface, Sidewalk, Driveway, Deck, Exterior, and Commercial Cleaning
PRODUCT NOTICE:
As a parts distributor we mostly sell aftermarket parts (any OEM parts would be noted as such). Aftermarket parts are not sourced from the original vehicle or equipment manufacturer, but are designed to function the same as - if not better than - the original. All parts sold are new.
WARNING - This product may expose you to chemicals which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
