New Hub Assembly Compatible With Chrysler Pacifica 3.8L 4.0L 2007 2008 By Part Numbers Br930644

THIS ITEM FITS VARIOUS APPLICATIONS BY PART NUMBER. PLEASE CHECK YOUR PART NUMBER TO ENSURE FITMENT.

PRODUCT TYPE: HUB ASSEMBLY

SPECIFICATIONS:
ABS CONNECTOR SHAPE: RECTANGLE
ABS SENSOR INCLUDED: YES
ABS SENSOR RING INCLUDED: YES
ABS SENSOR RING TYPE: SENSOR
BEARING TYPE: BALL
DRIVEN OR NON-DRIVEN: DRIVEN
FLANGE BOLT SIZE (IN): 1.339
FLANGE BOLT SIZE (MM): 34
FLANGE BOLT THREAD SIZE: M12X1.5
FLANGE DIAMETER (INCH): 3.224
FLANGE OFFSET (INCH): 1.913
FLANGE SHAPE: CIRCULAR
GASKET OR SEAL INCLUDED: YES
GREASEABLE: YES
HUB CENTERBORE DIAMETER (IN): 5
HUB CENTERBORE DIAMETER (MM): 127
HUB DIAMETER (IN): 6.591
HUB PILOT DIAMETER (INCH): 3.346
LUG BOLT THREAD SIZE: M10X1.5
LUG BOLTS INCLUDED: 4
MATERIAL: CHROME STEEL
NEW OR REMANUFACTURED: NEW
NUMBER OF ABS SENSOR RING TEETH: 47
NUMBER OF BOLT HOLES: 4
NUMBER OF BOLTS TO KNUCKLE: 4
NUMBER OF FLANGE BOLTS INCLUDED: 5
NUMBER OF LUG BOLTS INCLUDED: 4
NUMBER OF LUGS: 4
NUMBER OF MOUNTING BOLTS TO KNUCKLE: 4
NUMBER OF TERMINALS: 1
ROLL-FORMED: YES
SPLINE QUANTITY: 32
TERMINAL GENDER: FEMALE
TOTAL HUB DIAMETER (IN): 6.591
TOTAL HUB DIAMETER (MM): 167.4
TOTAL HUB HEIGHT (IN): 4.24
TOTAL HUB HEIGHT (MM): 107.7
WIRING HARNESS INCLUDED: YES
WIRING HARNESS LENGTH (IN): 37.992

REPLACES:
AUTOPART INTERNATIONAL: 1411-246653
BCA: WE60508
CENTRIC PARTS: 40263002
FAG US: 102220
GSP: 124261
MEVOTECH: H513261
MOOG HUB ASSEMBLIES: 513261
NAPA: PBR930644

APPLICATIONS:
CHRYSLER PACIFICA (2007-2008)
