New Hub Assembly Compatible With Mazda Ford Lincoln Mercury 6 Fusion Zephyr Milan Mkz 2003 2004 2005

THIS ITEM FITS VARIOUS APPLICATIONS BY PART NUMBER. PLEASE CHECK YOUR PART NUMBER TO ENSURE FITMENT.

PRODUCT TYPE: HUB ASSEMBLY
ASSEMBLY/SINGLE: SINGLE

SPECIFICATIONS:
ABS SENSOR INCLUDED: YES
ABS SENSOR RING DIAMETER (IN): 3.54
ABS SENSOR RING DIAMETER (MM): 90
ABS SENSOR RING INCLUDED: YES
ABS SENSOR RING TYPE: TONE
BEARING TYPE: BALL
DRIVEN OR NON-DRIVEN: NON-DRIVEN
FLANGE BOLT SIZE (IN): 1.33
FLANGE BOLT SIZE (MM): 33
FLANGE BOLT THREAD SIZE: M12-1.50
FLANGE DIAMETER (INCH): 2.83
FLANGE OFFSET (INCH): 2.4
FLANGE SHAPE: ROUND
GASKET OR SEAL INCLUDED: YES
GREASEABLE: YES
HUB CENTERBORE DIAMETER (IN): 4.5
HUB CENTERBORE DIAMETER (MM): 114
HUB DIAMETER (IN): 5.51
HUB PILOT DIAMETER (INCH): 1.417
LUG BOLT THREAD SIZE: M12-1.50
LUG BOLTS INCLUDED: 5
MATERIAL: CHROME STEEL
NEW OR REMANUFACTURED: NEW
NUMBER OF ABS SENSOR RING TEETH: 44
NUMBER OF BOLT HOLES: 5
NUMBER OF BOLTS TO KNUCKLE: 0
NUMBER OF LUG BOLTS INCLUDED: 5
NUMBER OF LUGS: 5
NUMBER OF MOUNTING BOLTS TO KNUCKLE: 0
ROLL-FORMED: NO
TOTAL HUB DIAMETER (IN): 5.51
TOTAL HUB DIAMETER (MM): 140
TOTAL HUB HEIGHT (IN): 3.73
TOTAL HUB HEIGHT (MM): 94
WIRING HARNESS INCLUDED: NO

REPLACES:
OTHER PART NUMBER: PT512271
SKF: BR930411
TIMKEN: HA590100
AUTOPART INTERNATIONAL: 1411-09824
BCA: WE60556
BECK/ARNLEY: 051-6229
CENTRIC PARTS: 40645004
FAG US: 102109
GSP: 474131
MEVOTECH: H512271
MOOG HUB ASSEMBLIES: 512271
NAPA: PBR930411

APPLICATIONS:
MAZDA 6 (2003-2008)
FORD FUSION (2006-2012)
LINCOLN ZEPHYR (2006-2006)
MERCURY MILAN (2006-2010)
LINCOLN MKZ (2007-2012)
