New Hub Assembly Compatible With Cadillac Sts 3.6L 4.4L 4.6L 2005 2006 2007 2008 2009 2010 2011 By

THIS ITEM FITS VARIOUS APPLICATIONS BY PART NUMBER. PLEASE CHECK YOUR PART NUMBER TO ENSURE FITMENT.

PRODUCT TYPE: HUB ASSEMBLY
ASSEMBLY/SINGLE: SINGLE

SPECIFICATIONS:
ABS CONNECTOR SHAPE: OVAL
ABS SENSOR INCLUDED: NO
ABS SENSOR RING DIAMETER (IN): 2.608
ABS SENSOR RING DIAMETER (MM): 66
ABS SENSOR RING INCLUDED: NO
ABS SENSOR RING TYPE: TONE
BEARING TYPE: BALL
DRIVEN OR NON-DRIVEN: DRIVEN
FLANGE BOLT SIZE (IN): 1.539
FLANGE BOLT SIZE (MM): 39
FLANGE BOLT THREAD SIZE: M12-1.50
FLANGE DIAMETER (INCH): 2.779
FLANGE OFFSET (INCH): 42
FLANGE SHAPE: ROUND
GASKET OR SEAL INCLUDED: YES
GREASEABLE: YES
HUB CENTERBORE DIAMETER (IN): 4.527
HUB CENTERBORE DIAMETER (MM): 115
HUB DIAMETER (IN): 5.728
HUB PILOT DIAMETER (INCH): 3.592
LUG BOLT THREAD SIZE: M12-1.75
MATERIAL: CHROME STEEL
NEW OR REMANUFACTURED: NEW
NUMBER OF ABS SENSOR RING TEETH: 47
NUMBER OF BOLTS TO KNUCKLE: 3
NUMBER OF FLANGE BOLTS INCLUDED: 5
NUMBER OF LUG BOLTS INCLUDED: 5
NUMBER OF LUGS: 5
NUMBER OF MOUNTING BOLTS TO KNUCKLE: 3
NUMBER OF TERMINALS: 1
ROLL-FORMED: NO
SPLINE QUANTITY: 30
TERMINAL GENDER: MALE
TOTAL HUB DIAMETER (IN): 5.728
TOTAL HUB DIAMETER (MM): 145
TOTAL HUB HEIGHT (IN): 4.261
TOTAL HUB HEIGHT (MM): 108
WIRING HARNESS INCLUDED: NO
WIRING HARNESS LENGTH (IN): 3.125

REPLACES:
ACDELCO: FW171
AUTOPART INTERNATIONAL: 1411-49172
BCA: WE60894
CENTRIC PARTS: 40262010
GENERAL MOTORS: 89060208
GSP: 104238
MEVOTECH: H513238
MOOG HUB ASSEMBLIES: 513238
NAPA: PBR930081

APPLICATIONS:
CADILLAC STS (2005-2011)
