New Hub Assembly Compatible With Ram Promaster City 2.4L 2015 2016 2017 2018 2019 2020 2021 2022 By

THIS ITEM FITS VARIOUS APPLICATIONS BY PART NUMBER. PLEASE CHECK YOUR PART NUMBER TO ENSURE FITMENT.

PRODUCT TYPE: HUB ASSEMBLY

SPECIFICATIONS:
ABS SENSOR INCLUDED: NO
ABS SENSOR RING DIAMETER (IN): 2.98
ABS SENSOR RING DIAMETER (MM): 75
ABS SENSOR RING INCLUDED: NO
ABS SENSOR RING TYPE: MAGNETIC
BEARING TYPE: BALL
DRIVEN OR NON-DRIVEN: NON-DRIVEN
FLANGE BOLT THREAD SIZE: M12-1.25
FLANGE DIAMETER (INCH): 2.32
FLANGE OFFSET (INCH): 2.13
FLANGE SHAPE: ROUND
GASKET OR SEAL INCLUDED: YES
GREASEABLE: NO
HUB CENTERBORE DIAMETER (IN): 3.78
HUB CENTERBORE DIAMETER (MM): 96
HUB DIAMETER (IN): 4.72
HUB PILOT DIAMETER (INCH): 2.98
INNER RING WIDTH (IN): 2.05
LUG BOLTS INCLUDED: 5
MATERIAL: CHROME STEEL
NEW OR REMANUFACTURED: NEW
NUMBER OF ABS SENSOR RING TEETH: 48
NUMBER OF BOLT HOLES: 5
NUMBER OF BOLTS TO KNUCKLE: 0
NUMBER OF LUG BOLTS INCLUDED: 5
NUMBER OF LUGS: 5
NUMBER OF MOUNTING BOLTS TO KNUCKLE: 0
OUTER RING WIDTH (IN): 2.81
ROLL-FORMED: NO
TOTAL HUB DIAMETER (IN): 4.72
TOTAL HUB DIAMETER (MM): 120
TOTAL HUB HEIGHT (IN): 2.81
TOTAL HUB HEIGHT (MM): 71
WIRING HARNESS INCLUDED: NO

REPLACES:
AUTOPART INTERNATIONAL: 1411-612759
CENTRIC PARTS: 40663011
MOOG HUB ASSEMBLIES: 512577
MOPAR: 68263146AA

APPLICATIONS:
RAM PROMASTER CITY (2015-2022)
