24V 150A Electric Pump Motor Compatible With Scott Motors 2200856 2200945 4Bd-02273 Skyjack 106576

10773*1
SCOTT MOTORS:
• 2200856 (2200-856)
• 2200945 (2200-945)
• 4BD-02273 (4BD2273)
• W4BD-2273

SKYJACK:
• 106576
• 220856
• SJ-106576
• 107486

WESTERN MOTOR:
• W-2273

HALDEX-BARNES:
• 220-0856

SPECIFICATIONS:
• Voltage: 24V
• Amperage: 150A Full Load
• Power: 4HP (3.0kW)
• Speed: 3600 RPM
• Rotation: CW (Clockwise)
• Motor Type: Permanent Magnet (PM)
• Unit Type: JS Barnes
• Case Diameter: 114.3mm / 4.500in
• Overall Length: 370mm / 14.567in
• Shaft OD: 15mm
• Shaft Type: Amplex / Chrysler Coupler with 1/4-20 Threaded Hole
• Terminals: (2) 5/16-24
• Mounting: DE Housing Drilled for (4) 1/4-20 Holes
• Bearings: Double Ball Bearing
• Weight: 34 lbs

PRODUCT NOTICE:
As a parts distributor we mostly sell aftermarket parts (any OEM parts would be noted as such). Aftermarket parts are not sourced from the original vehicle or equipment manufacturer, but are designed to function the same as - if not better than - the original. All parts sold are new.

WARNING - This product may expose you to chemicals such as Lead, Carbon Black, Silica, Crystalline which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov

Was: $2,194.52
Sale: $1,254.01
Save: 43%
Save: $940.51
Qty:
Free Shipping!

Description

SKYJACK ELECTRIC SCISSOR LIFTS:
• SJIII3015 Electric Scissor Lift
• SJIII3215 Electric Scissor Lift
• SJIII3219 Electric Scissor Lift
• SJIII3220 Electric Scissor Lift
• SJIII3226 Electric Scissor Lift
• SJIII4620 Electric Scissor Lift
• SJIII4626 Electric Scissor Lift
• SJIII4632 Electric Scissor Lift

GENERAL EQUIPMENT:
• Aerial Lifts - Hydraulic Pump Motor
• Scissor Lifts - Hydraulic Pump Motor
• Haldex-Barnes Hydraulic Pump Systems
• JS Barnes Hydraulic Pump Systems

MOTOR SPECIFICATIONS:
• 24 Volt DC Permanent Magnet Motor
• Clockwise Rotation
• Amplex (Male) Shaft / Chrysler Coupler Type
• 4HP / 3600RPM / 150A Full Load
• 4.5in Diameter Case / 14.2in Overall Length
• DE Housing Drilled for (4) 1/4-20 Mounting Holes
• Double Ball Bearings / 100% New

Details

Shipping Information

  • Item Requires Shipping
  • 33.0 lbs.
  • W10.0000” x H10.0000” x L21.0000”
  • Free Shipping!
