OEM PART NUMBERS:
• 70091739 (Waltco)
• 2200072 (Haldex-Barnes)
• 39200398 (Haldex-Barnes / MTE Hydraulics)
• 229272 (Maxon)
• 8100 (Monarch)
• 4422590 (Thieman)
• W-8943 (Western Motor)
• W-8943D (Western Motor)
• W-8943DBB (Western Motor)
• DCM-0007 (Reference Number)
• BMT0127 (National Liftgate Parts)
• PLMMY6302 (OEM)
PRESTOLITE PART NUMBERS:
• 46-2054
• 46-2495
• 46-2516
• 46-2534
• 46-4038
• 46-4154
• MFX4003
• MFX4003S
• MMW4001
• MMW4002
• MMW4002S
• MMY4001
• MMY4001A
• MMY4001S
• MMY4004
• MMY4004S
• MMY6101A
• MMY6101AS
• MMY6302
SPECIFICATIONS:
• Voltage: 12V DC
• Rotation: CCW (Counter Clockwise)
• Shaft Type: Slotted Shaft
• Bearing: Double Ball Bearing
• Field Housing OD: 113.6mm / 4.472 inch
• Overall Length: 178.6mm / 7.031 inch
• Shaft OD: 15.4mm / 0.606 inch
• Terminal Size: 5/16-24
• Weight: 18 lbs / 8.18 kg
• Motor Type: 4.5 inch HD Motor
• Field Case: 6.875 inch
• Thru Bolt Position: 3:00 and 9:00
• Switch Mount: 1/4-20 threaded holes
FITS EQUIPMENT:
• Waltco Liftgates
• Maxon Liftgates
• Thieman Tailgates
• Leyman Liftgates
• MTE Hydraulics Power Units
• JS Barnes / Haldex-Barnes Power Units
• Monarch Hydraulics Power Units
• Fenner Stone Power Units
• Leece Neville Applications
PRODUCT NOTICE:
As a parts distributor we mostly sell aftermarket parts (any OEM parts would be noted as such). Aftermarket parts are not sourced from the original vehicle or equipment manufacturer, but are designed to function the same as - if not better than - the original. All parts sold are new.
WARNING - This product may expose you to chemicals such as Lead, Carbon Black, Silica, Crystalline which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
