OEM PART NUMBERS:
• Yamaha: J38-81100-10-00
• Yamaha: J38-81100-11-00
• Yamaha: J38-81100-00
• Yamaha: J38-81100-10
• Yamaha: J38-81100-11
• Hitachi: GSB107-06B
• Hitachi: GSB-107-06B
• Redhawk: MOT-2000
SPECIFICATIONS:
• Unit Type: Starter Generator Motor
• Voltage: 12V DC
• Rotation: Reversible
• Current Type: DC
• Field Housing OD: 112.7mm / 4.437in
• Overall Length: 229.2mm / 9.024in
• Shaft OD: 17mm / 0.669in
• Shaft: Threaded With Keyway
• Terminal 1 Size: M6-1.0
• Terminal 2 Size: M6-1.0
• Terminal 3 Size: M6-1.0
• Terminal 4 Size: M6-1.0
• Configuration: 4 Terminal 2 Wire
• Terminals: 5 Total
• Mounting: 13mm and 8.5mm Top Holes, 13mm Bottom Holes
• Weight: 18.065 lbs / 8.21 kg
FITS YAMAHA GOLF CARTS:
• Yamaha G2A Gas Engine (1985-1991)
• Yamaha G5A Sun Classic Gas Engine (1990-1995)
• Yamaha G8A Fleet Classic Gas Engine (1990-1994)
• Yamaha G9A Fleet Master Gas Engine (1991-1995)
• Yamaha G11A Yamahauler Gas Engine (1993-1994)
• Yamaha G14A Ultima Gas Engine (1995-1996)
ALSO FITS:
• Hyundai Golf Carts (1990-1995)
• Taylor-Dunn Model R-680 Truck (1986-1997)
PRODUCT NOTICE:
As a parts distributor we mostly sell aftermarket parts (any OEM parts would be noted as such). Aftermarket parts are not sourced from the original vehicle or equipment manufacturer, but are designed to function the same as - if not better than - the original. All parts sold are new.
WARNING - This product may expose you to chemicals such as Lead, Carbon Black, Silica, Crystalline which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
