HONDA OEM PART NUMBERS:
• 31200-371-005
• 31200-371-505
• 31200-371-405
• 31200-371-980
STARTER REFERENCE:
• SM2 Family Starter
SPECIFICATIONS:
• Unit Type: SM2 Family
• Starter Type: PMDD
• Power Output: 0.6kW
• Voltage: 12V
• Rotation: CW (Clockwise)
• Drive Teeth: 13
• Teeth/Splines: 31
• Pinion OD: 13.6mm / 0.535in
• Gear OD: 38.8mm / 1.528in
• Body Length: 187.4mm / 7.378in
• Registry OD: 45.9mm / 1.807in
• Mounting Hole 1: 6.6mm ID Unthreaded
• Mounting Hole 2: 6.6mm ID Unthreaded
• Mounting Hole Distance: 144mm / 5.6in
• Overall Dimensions: 189.8mm L x 72.7mm W x 67mm H
• Brushes: 4-Brush Configuration
• Weight: 5.575 lbs / 2.53 kg
FITS HONDA MOTORCYCLES:
• GL1000 Gold Wing 999cc (1975-1979)
• GL1000 Gold Wing LTD 999cc (1976)
PRODUCT NOTICE:
