HONDA OEM PART NUMBERS:
• 31200-463-008
• 31200-463-405
STARTER REFERENCE:
• SM224 (SM2-24)
SPECIFICATIONS:
• Unit Type: SM224 (SM2-24)
• Starter Type: PMDD
• Power Output: 0.6kW
• Voltage: 12V
• Rotation: CW (Clockwise)
• Drive Teeth: 13
• Teeth/Splines: 31
• Pinion OD: 13.6mm / 0.535in
• Gear OD: 38.8mm / 1.528in
• Body Length: 187.4mm / 7.378in
• Registry OD: 45.9mm / 1.807in
• Mounting Hole 1: 6.6mm ID Unthreaded
• Mounting Hole 2: 6.6mm ID Unthreaded (Oblong 6.6 x 13.1mm)
• Mounting Hole Distance: 144mm / 5.6in
• Brushes: 4-Brush Configuration
• Weight: 5.575 lbs / 2.53 kg
FITS HONDA MOTORCYCLES:
• GL1100 Gold Wing 1084cc (1980-1983)
• GL1100A Gold Wing Aspencade 1084cc (1982-1983)
• GL1100D Gold Wing Deluxe 1084cc (1980-1982)
• GL1100I Gold Wing Interstate 1084cc (1980-1983)
PRODUCT NOTICE:
As a parts distributor we mostly sell aftermarket parts (any OEM parts would be noted as such). Aftermarket parts are not sourced from the original vehicle or equipment manufacturer, but are designed to function the same as - if not better than - the original. All parts sold are new.
WARNING - This product may expose you to chemicals such as Lead, Carbon Black, Silica, Crystalline which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
