Tilt Trim Motor Compatible With Yamaha F50la F50lb F60ja F60jb F60la F60lb T50la T50lb T60la T60lb

OEM PART NUMBERS:
• Yamaha: 6C5-43880-01-00 / 6C5438800100 / 6C5-43880-01 / 6C54388001
• Yamaha: 6C5-43880-00-00 / 6C5438800000 / 6C5-43880-00 / 6C54388000
• Quicksilver: 8M6007564



AFTERMARKET CROSS REFERENCE:
• API Marine: PT625NM
• Arco Marine: 6257
SPECIFICATIONS:
• Type: Tilt Trim Motor
• Voltage: 12V DC
• Rotation: Reversible
• Connection: 2-Wire with Ring Terminals
• Shaft OD: 8mm / 0.315in
• Shaft Type: Slotted
• Field Housing OD: 64mm / 2.52in
• Overall Length: 146.8mm / 5.78in
• Mounting: 3-Bolt
• Weight: 6 lbs
• Condition: New

YAMAHA APPLICATIONS (2003-2016):
• F50: F50TLR (2003, 2005-2012), F50LA (2013), F50LB (2014-2016)
• F60: F60TJR/TLR (2003, 2005-2012), F60JA/LA (2013), F60JB/LB (2014-2016)
• T50: T50TLR (2003, 2005), T50LA (2013), T50LB (2014-2016)
• T60: T60TLR (2003, 2005-2012), T60LA (2013), T60LB (2014-2016)
