OEM PART NUMBERS:
• Ohio Motors: D468210XWF02, D468237XWF07A, D468242XWF07, D468247XW07A, D468247XWF07A, D468250XWF07, D468250XWF07A, D468255XWF07A, D482252X7707A
• Prestolite: MBD5112, MBD5112S
• JS Barnes / Haldex: 2200353, 2200858, 2200980
• JLG: 3160263, 3160264, 7011041
• Western Motor: W-5112, W5112
SPECIFICATIONS:
• Voltage: 24V DC
• Power: 4 HP
• Rotation: CW (Clockwise)
• Field Housing OD: 127mm / 5.000in
• Overall Length: 285mm / 11.220in
• Shaft: Chrysler Amplex Coupler Type
• Terminal 1: 3/8-16
• Terminal 2: 3/8-16
• Bearings: Double Ball Bearing
• Housing: Cast Aluminum Comm. and Drive Ends with Black Field Case
• Weight: 34.5 lbs / 15.68 kg
• Condition: New
APPLICATION:
• JLG E2 Series Scissor Lifts (1998-2012)
• Haldex Barnes Hydraulic Pump Systems
24V CW Electric Hydraulic Motor - Ohio D482252X7707A Replacement
New 24 Volt clockwise electric pump motor cross-referencing Ohio Motors D482252X7707A, Prestolite MBD5112S, and JS Barnes Haldex 2200980 for hydraulic pump assemblies in material handling equipment. This 4 HP motor utilizes a Chrysler Amplex coupler type shaft with double ball bearing support for smooth, reliable operation. The 5-inch diameter cast aluminum housing provides excellent durability and heat dissipation. Fits all JLG E2 series electric scissor lifts including 1532E2, 1932E2, 2032E2, 2632E2, 2646E2, and 3246E2 produced from 1998 to 2012.
PRODUCT NOTICE:
As a parts distributor we mostly sell aftermarket parts (any OEM parts would be noted as such). Aftermarket parts are not sourced from the original vehicle or equipment manufacturer, but are designed to function the same as - if not better than - the original. All parts sold are new.
WARNING - This product may expose you to chemicals such as Lead, Carbon Black, Silica, Crystalline which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
