OEM PART NUMBERS: • Denso: 228000-5400 / 2280005400, 228000-5401 / 2280005401, 228000-5910 / 2280005910, 228000-5911 / 2280005911, 228000-7090 / 2280007090, 228000-7091 / 2280007091, 228000-7480 / 2280007480, 228000-7481 / 2280007481, 428000-1160 / 4280001160, 428000-1161 / 4280001161, 428000-9520 / 4280009520, DSN2076, 9722809-540 / 9722809540
• Kubota: 6A320-59210 / 6A32059210, 6A320-59211 / 6A32059211, 6A320-59212 / 6A32059212, 6A320-59213 / 6A32059213, K3511-81410 / K351181410, K3511-81411 / K351181411, 1G023-63010 / 1G02363010, 1G023-63011 / 1G02363011, 1G069-63010 / 1G06963010, 1G069-63011 / 1G06963011, 1G069-63012 / 1G06963012, 1J813-63010 / 1J81363010, 67980-31150 / 6798031150, 67980-31151 / 6798031151, 67980-31152 / 6798031152, EG523-63010 / EG52363010, EG523-63011 / EG52363011, 77700-02596 / 7770002596
• Genie: 139191, 139191GT, 23456, 52810GT, 67980350KU
• Skyjack: 136100, SJ136100, 115309, 216536
• Toro: 100-2179 / 1002179
• Onan: 185-7104 / 1857104
• Lucas: LRS02300, LRS02702
SPECIFICATIONS: • Type: Starter
• Voltage: 12V
• Output: 0.9kW
• Rotation: Clockwise (CW)
• Design: PLGR Planetary Gear Reduction
• Pinion: 9T
• Pinion Outside Diameter: 29mm / 1.142in
• Drive End Housing Number: 228400-5400
• Mounting Ear 1: 9mm Unthreaded
• Mounting Ear 2: 9mm Unthreaded
• Weight: 7.1 lb / 3.23 kg
• Engine: Kubota D722, D782, D902, D1005, D1105, V1305, WG972, DF972
• Polarity: Negative Ground
• Condition: New
APPLICATIONS: • Kubota F2260, F2260-R, F2560-E, F2560-R and F3060-R front mower 1996-2005
• Kubota ZD18, ZD21, ZD25 and ZD28F zero-turn mower 2001-2006
• Kubota ZD221, ZD321, ZD323-60, ZD326 and ZD331 zero-turn mower 2007-2016
• Kubota G2160, GR2100, GR2110, GR2120, TG1860 and BX1500 1998-2016
• Genie Z-34/22 IC boom lift on the Kubota WG972 and DF972 2001-2016
• Skyjack SJ6826 RT and SJ6832 RT scissor lift on the DF972 and D902 2005-2016
• Toro Dingo TX525 and 320-D, Bobcat 2200, Ingersoll Rand TC-13
• Nilfisk-Advance Proterra sweeper on the Kubota DF972 2001-2016
• Aixam 400, 500, A.721, City and Crossline microcar 1997-2012
PRODUCT NOTICE:
As a parts distributor we mostly sell aftermarket parts (any OEM parts would be noted as such). Aftermarket parts are not sourced from the original vehicle or equipment manufacturer, but are designed to function the same as - if not better than - the original. All parts sold are new.
