OEM PART NUMBERS: • Denso: 104211-0120 / 1042110120, 104211-0121 / 1042110121, TN104211-0121 / TN1042110121, 104211-012 / 104211012
• Chrysler: 56029696AA, 56029696AB, P56029696AA, P56029696AB
• Bosch: AL6547X
• Bosch Service Europe: 0986UR6317, 0986CR6317
• IAT: A11781
• PIC: 290-6400 / 2906400
• Voltux: V2-11781 / V211781
SPECIFICATIONS: • Type: Alternator
• OE Manufacturer: Denso
• Family: Denso SC Hairpin
• Voltage: 12V
• Amperage: 230A
• Rotation: Clockwise
• Regulator Clock Position: 12:00
• Regulator Location: Internal
• Fan Location: Internal
• Mount Hole ID 1: 11mm Slotted
• Mount Hole ID 2: 11mm Unthreaded
• Mount Hole 3: Unthreaded
• Mount Hole ID 4: 11mm Unthreaded
• Mounting Foot ID: 9mm
• Mounting Ear 2 Width: 59mm
• Mounting Ear 3 Width: 59mm
• Mounting Ear 4 Width: 59mm
• Mounting Foot Width: 59mm
• Terminal: B+ M8-1.25
• Terminal 2: LIN Communication
• Number Of Grooves: 6
• Groove Outside Diameter: 51mm
• Pulley Type: Serpentine Clutch Decoupler
• Pulley Outside Diameter: 53mm
• Condition: New
APPLICATIONS: • Ram 1500 3.0 182cid V6 Turbo Diesel 2014-2018
• Ram 1500 Classic 3.0 182cid V6 Turbo Diesel 2019
• Ram 1500 Tradesman Big Horn Lone Star and Outdoorsman 2014-2018
• Ram 1500 Laramie Laramie Longhorn Limited and HFE 2014-2018
PRODUCT NOTICE:
As a parts distributor we mostly sell aftermarket parts (any OEM parts would be noted as such). Aftermarket parts are not sourced from the original vehicle or equipment manufacturer, but are designed to function the same as - if not better than - the original. All parts sold are new.
WARNING - This product may expose you to chemicals such as Lead, Carbon Black, Silica, Crystalline which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
