OEM PART NUMBERS: • John Deere: RE537507, RE537807, RE544809, SE502560, DZ123153, RM100227, 150CT13
• Bosch: 0124325207, 0124325225, 0124325249
• SEG Automotive: 0124325265, F000BL04AM
SPECIFICATIONS: • Type: Alternator
• OE Manufacturer: Bosch
• Voltage: 12V system, 14V regulated output
• Amperage: 90A
• Rotation: Clockwise
• Regulator: Internal, 12:00 clock position
• Fan: Internal
• Frame: Open, enclosed brush
• Polarity: Negative ground
• Mounting: Pad, 4 hole, 107.95mm pad span
• Mount Holes 1 and 3: 12.5mm unthreaded
• Mount Holes 2 and 4: 10.6mm unthreaded
• Pad Width: 80mm / 3.150 in
• Terminals: B+ M8-1.25, W pin and M5-0.8 stud, S M5-0.8, D+ M5-0.8
• Pulley: 8 groove serpentine, 59mm OD, 54mm groove OD
• Shaft: M16x1.50, 22.2mm pulley seat
• Condition: New
APPLICATIONS: • John Deere 344K and 344L loader 4045 4.5L 2013-2025
• John Deere 5075M, 5085E and 5085M tractor 2008-2025
• John Deere 5090E, 5090M, 5100E, 5100M, 5100MH, 5100ML 2009-2025
• John Deere 5115M, 5115ML and 5125ML tractor 2012-2025
• John Deere 6100E, 6105D, 6105E, 6105EH and 6110E 2010-2024
• John Deere 6115D, 6115E, 6120E, 6120EH, 6130D, 6130E 2008-2024
• John Deere 6135E and 6140D iT4 tractor 2010-2024
• John Deere 4045, 6068, 6090, 6135 and 6136 industrial engines
PRODUCT NOTICE:
As a parts distributor we mostly sell aftermarket parts (any OEM parts would be noted as such). Aftermarket parts are not sourced from the original vehicle or equipment manufacturer, but are designed to function the same as - if not better than - the original. All parts sold are new.
WARNING - This product may expose you to chemicals such as Lead, Carbon Black, Silica, Crystalline which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
