VOLKSWAGEN OEM PART NUMBERS: • Volkswagen: 03H903026A / 03H-903-026-A / 03H 903 026 A
• Volkswagen: 03H903026AX / 03H-903-026-AX / 03H 903 026 AX
VALEO PART NUMBERS: • Valeo: 439783
• Valeo Remanufactured: 200217
• Valeo Remanufactured: 440415
SPECIFICATIONS: • Type: Alternator
• Voltage: 12V
• Rated Voltage: 14V
• Amperage: 180 Amp
• Rotation: Clockwise
• Regulator: Internal
• Fan: Internal
• Pulley: Six Groove Serpentine
• Pulley Type: Overrunning Clutch
• Pulley Diameter: 51mm
• Terminal: B Plus M8
• Mounting: Four Point
• Ground: Negative
• Condition: New Aftermarket
VOLKSWAGEN APPLICATIONS: • Volkswagen Atlas (2021-2023) — 3.6L VR6 3598cc CDVC
• Volkswagen Atlas Cross Sport (2021-2023) — 3.6L VR6 3598cc CDVC
ENGINE: • 3.6L VR6 naturally aspirated
• 3598cc 220 cubic inch
• Engine code CDVC
• Front wheel drive and 4Motion take the same alternator
THE SUFFIX: • 03H903026A is the new Volkswagen part
• 03H903026AX is the same part on core exchange
• The X marks the exchange unit and nothing else
• Both numbers describe this alternator
WHAT THIS UNIT IS: • Engine: 3.6L VR6 3598cc CDVC naturally aspirated
• Output: 12V 180 Amp clockwise six groove clutch pulley
• Case number: 03H903026A or 03H903026AX
• Model years: 2021 2022 and 2023
• Drivetrain: front wheel drive and 4Motion both take this unit
• The VR6 Atlas was built with two alternator outputs — read the case
PRODUCT NOTICE:
As a parts distributor we mostly sell aftermarket parts (any OEM parts would be noted as such). Aftermarket parts are not sourced from the original vehicle or equipment manufacturer, but are designed to function the same as - if not better than - the original. All parts sold are new.
WARNING - This product may expose you to chemicals such as Lead, Carbon Black, Silica, Crystalline which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
