Alternator 12V Cw Compatible With 2014-16 Audi A6 3.0 Tfsi

(0) Reviews: Write first review
20664A4
AUDI AND VOLKSWAGEN OEM PART NUMBERS:
• Audi: 06E903019B / 06E-903-019-B / 06E 903 019 B
• Audi: 06E903019BX / 06E-903-019-BX — core exchange
• Audi: 06E903019G / 06E-903-019-G / 06E 903 019 G
• Audi: 06E903019GX / 06E-903-019-GX — core exchange

VALEO PART NUMBERS:
• Valeo New: 439939
• Valeo Remanufactured: 440683
• Valeo Type: FG20S024 / FGN20S024
• Valeo Type: FG20S038 / FGN20S038

SPECIFICATIONS:
• 12 Volt / 14V Rated / 180 Amp / Clockwise (CW) Rotation
• Internal Regulator, Internal Fan, Negative Ground
• Pulley: 6-Groove Serpentine SOLID (S6) / 66.0mm OD
• Terminals: B Plus and COM
• Weight: 7.23 kg • Design: IR/IF
• Condition: New Aftermarket

AUDI APPLICATIONS:
• Audi A6 Quattro C7 3.0 TFSI 2995cc 245kW 333HP
• Audi A6 Avant Quattro C7 3.0 TFSI 2995cc 245kW
• Audi A6 Allroad Quattro C7 3.0 TFSI 2995cc 245kW
• Audi A7 Quattro C7 3.0 TFSI 2995cc 245kW 333HP
• Audi A7 Sportback Quattro C7 3.0 TFSI 2995cc
• Engine codes: CREC CGXB CGWD CTUA CTTA
• Build date to 08/15/2016

THE X SUFFIX:
• 06E903019B and 06E903019G — new parts
• 06E903019BX and 06E903019GX — same parts on core exchange
• The X marks the exchange unit and nothing else
• All four numbers describe one alternator

WHAT THIS UNIT IS:
• Output: 12 Volt 180 Amp clockwise
• Pulley: 6-groove serpentine SOLID 66.0mm — no freewheel clutch
• Case number: 06E903019B 06E903019G 439939 or FG20S024
• Build date: to 08/15/2016
• Engine: 3.0 TFSI supercharged V6 2995cc
• Vehicle: Audi A6 and A7 C7 Quattro

PRODUCT NOTICE:
As a parts distributor we mostly sell aftermarket parts (any OEM parts would be noted as such). Aftermarket parts are not sourced from the original vehicle or equipment manufacturer, but are designed to function the same as - if not better than - the original. All parts sold are new.

WARNING - This product may expose you to chemicals such as Lead, Carbon Black, Silica, Crystalline which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov

Was: $1,273.76
Sale: $727.86
Save: 43%
Save: $545.90
Qty:
Free Shipping!

Description

ALTERNATOR 12V 180 Amp CW S6 — AUDI A6 AND A7 C7 3.0 TFSI:

THREE CHECKS BEFORE YOU BUY:
• Engine: 3.0 TFSI supercharged V6 2995cc 245kW 333HP
• Build date: to 08/15/2016
• Pulley: 6-groove serpentine SOLID with no freewheel clutch
• Case number: 06E903019B 06E903019G 439939 or FG20S024
• Output: 180 Amp clockwise

AUDI A6 C7 QUATTRO:
• Audi A6 Quattro 3.0 TFSI 2995cc 245kW 333HP (2014)
• Audi A6 Quattro 3.0 TFSI 2995cc 245kW 333HP (2015)
• Audi A6 Quattro 3.0 TFSI 2995cc 245kW 333HP (2016 to 08/15)
• Audi A6 Avant Quattro 3.0 TFSI 2995cc 245kW (2014-2016)
• Audi A6 Allroad Quattro 3.0 TFSI 2995cc 245kW (2014-2016)
• Audi A6 Premium Premium Plus and Prestige 3.0 TFSI

AUDI A7 C7 QUATTRO:
• Audi A7 Quattro 3.0 TFSI 2995cc 245kW 333HP (2014)
• Audi A7 Quattro 3.0 TFSI 2995cc 245kW 333HP (2015)
• Audi A7 Quattro 3.0 TFSI 2995cc 245kW 333HP (2016 to 08/15)
• Audi A7 Sportback Quattro 3.0 TFSI 2995cc (2014-2016)
• Audi A7 Premium Plus and Prestige 3.0 TFSI

ENGINE CODES:
• Audi 3.0 TFSI engine code CREC
• Audi 3.0 TFSI engine code CGXB
• Audi 3.0 TFSI engine code CGWD
• Audi 3.0 TFSI engine code CTUA
• Audi 3.0 TFSI engine code CTTA
• Supercharged V6 2995cc 245kW 333HP

BUILD DATE — READ THIS FIRST:
• This alternator covers cars built to 08/15/2016
• Later production carries a different Audi number
• A 2016 car can sit on either side of the cutoff
• The model year alone does not answer it
• The build date is on the driver door jamb sticker

THE PULLEY IS SOLID:
• 6-Groove Serpentine SOLID pulley / 66.0mm outer diameter
• No freewheel and no overrunning clutch
• Other Audi 3.0 TFSI models run a clutch pulley on a near number
• A clutch pulley spins free in one direction by hand
• A solid pulley turns the rotor both ways

OEM PART NUMBERS:
• Audi: 06E903019B / 06E-903-019-B / 06E 903 019 B
• Audi: 06E903019BX / 06E-903-019-BX — core exchange
• Audi: 06E903019G / 06E-903-019-G / 06E 903 019 G
• Audi: 06E903019GX / 06E-903-019-GX — core exchange
• Valeo New: 439939 • Valeo Remanufactured: 440683
• Valeo Type: FG20S024 / FGN20S024 / FG20S038 / FGN20S038
• The X suffix marks the core exchange unit

TRIM AND BODY:
• Audi A6 Premium Premium Plus and Prestige 3.0 TFSI (2014-2016)
• Audi A7 Premium Plus and Prestige 3.0 TFSI (2014-2016)
• Audi A6 Avant and Allroad estate bodies 3.0 TFSI
• Audi A7 Sportback five door body 3.0 TFSI
• Quattro all wheel drive — one alternator across every trim

WHAT THIS UNIT IS:
• Output: 12 Volt 14V rated 180 Amp clockwise
• Pulley: 6-groove serpentine SOLID 66.0mm
• Regulator: Internal • Fan: Internal • Weight: 7.23 kg
• Terminals: B Plus and COM
• Engine: 3.0 TFSI supercharged V6 2995cc
• Vehicle: Audi A6 and A7 C7 Quattro built to 08/15/2016
