OEM PART NUMBERS: • Letrika: IA 1451 / IA1451, 11.204.913 / 11204913, AAK4634, 11.204.059 / 11204059, AAK3827
• Mahle: MG 721 / MG721
• JCB: 332/W4452, 332/W4452-S / 332/W4452S
SPECIFICATIONS: • 12V / 80A / Clockwise (CW) Rotation
• Regulated Output: 14V at the Terminal
• Design: IR/EF — Internal Regulator with External Fan
• Build: Letrika AAK — Dust-Proof Housing
• Pulley: One Groove Classic V-Belt at 80.0mm OD
• Mounting Bores: Two at 10.2mm
• Bore to Bore Distance: 75.0mm
• Mounting Point Diameter: 85.0mm
• Pulley to Housing: 45.0mm
• Weight: 4.85 kg / 10.7 lb
• Polarity: Negative Ground
• B Plus Terminal: Ring Connection
• Housing: Sealed Dust-Proof Slip Ring Compartment
• Condition: New
APPLICATIONS: • JCB 8085 ZTS midi excavator Isuzu 4LE2 (2009-2014)
• JCB 8085 ZTS zero tail swing eight tonne class
• JCB 8085 ZTS on JCB 332/W4452 and 332/W4452-S
• Isuzu 4LE2XYSJ-01 2.2L 134cid four cylinder diesel
• Isuzu 4LE2 turning this alternator on a single V-belt
