Engine Oil Pump Compatible With Caterpillar 226B2/232B/232B2 2005-2015 3013/3024/C2.2 1.5-2.2L

B339-3017A2
OEM PART NUMBERS:
• Caterpillar: 339-3017 (Primary OEM number - late version)
• Caterpillar: 3393017 (Alternative format of primary OEM)

SPECIFICATIONS:
• Drive Type: Gear driven
• Gear Type: Gerotor (inner rotor 4 lobes, outer rotor 5 lobes)
• Mounting Style: Flange-mounted engine block
• Drive Gear Teeth: 5
• Hub Diameter (mm): 62
• Engine Family: 3013/3024/C2.2
• Displacement: 1.5L
• Condition: New

APPLICATION:
• Compatible with Caterpillar 216B/216B3/226B/226B3 (2005-2015)
• Compatible with Caterpillar 906 (1998-2010)

PRODUCT NOTICE:
As a parts distributor we mostly sell aftermarket parts (any OEM parts would be noted as such). Aftermarket parts are not sourced from the original vehicle or equipment manufacturer, but are designed to function the same as - if not better than - the original. All parts sold are new.

WARNING - This product may expose you to chemicals such as Nickel which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov

Was: $487.74
Sale: $278.71
Save: 43%
Save: $209.03
Qty:
Free Shipping!

Description

CATERPILLAR SKID STEER LOADERS:
• Caterpillar 216B/216B3/226B/226B3 3013/3024/C2.2 1.5-2.2L Diesel (2005-2015)
• Caterpillar 226B2/232B/232B2/232D 3013/3024/C2.2 1.5-2.2L Diesel (2005-2015)
• Caterpillar 232D2/239D/242B/242B2 3013/3024/C2.2 1.5-2.2L Diesel (2005-2015)
• Caterpillar 247B/247B2/247B3/249D 3013/3024/C2.2 1.5-2.2L Diesel (2005-2015)
• Caterpillar 257B/257B2 3013/3024/C2.2 1.5-2.2L Diesel (2005-2015)

CATERPILLAR COMPACT LOADERS:
• Caterpillar 906 3034 3.3L Diesel (1998-2010)


IMPORTANT:
LATE version oil pump for Cat 3013/3024/C2.2 with 62mm hub. Replaces earlier 297-3050 (52mm hub) in production but is NOT a direct retrofit — hub diameter differs. Verify which hub size your engine requires before ordering.

Gerotor type (4-lobe inner, 5-lobe outer), flange-mounted. Used in Cat 216B-289D skid steers and 302.5-305.5 mini excavators. Failure: low hot idle pressure, intermittent shutdowns. Clean pickup screen and check relief valve before condemning pump.

⚠️ 62mm hub LATE variant — NOT interchangeable with 297-3050 (52mm hub).

Details

Shipping Information

  • Item Requires Shipping
  • 3.0 lbs.
  • W6.0000” x H5.0000” x L8.0000”
  • Free Shipping!
