OEM CROSS-REFERENCE PART NUMBERS:
• Carlisle: 5170011 (Snow Hog 2-Ply)
• Ariens: 07100230 (Sno-Thro Tire/Wheel Left Hand OEM)
• Ariens: 07101202 / 07101208 (Tire Assembly OEM)
• Ariens: 07100727 (K478 Tire OEM)
• John Deere: AM33136 (Snowblower Wheel Assembly OEM)
• MTD / Craftsman: 734-1709 (Snow Thrower OEM)
• MTD: 734-2038-0901 (Snow Thrower OEM)
• Cub Cadet: 734-04237 (Snowblower OEM)
• Oregon: 70-358 (Cross Reference)
• Rotary: 8919 (Cross Reference)
• R&R Products: RCT5170011 (Cross Reference)
• NHC: 222-5970 (Cross Reference)
• J. Thomas: JT-3055 (Cross Reference)
• Stens: 165-316 (Cross Reference)
TIRE SPECIFICATIONS:
• Size: 16x4.80-8 (Also Listed As 4.80-8 / 480-8)
• Tread Pattern: Snow Hog (X-Shaped Lug)
• Ply Rating: 2-Ply (Load Range A)
• Type: Tubeless
• Overall Diameter: 16.1 Inches
• Section Width: 4.70 Inches
• Rim Diameter: 8 Inches
• Rim Width: 3.75 Inches
• Tread Depth: 14/32 Inch
• Maximum Load: 440 lbs at 20 PSI
• Maximum PSI: 20
• Weight: Approx 12 lbs
• Service: NHS (Non-Highway)
• Construction: Bias Ply Tubeless
• Condition: New
APPLICATIONS:
• Ariens Sno-Thro Deluxe / Platinum / Professional
• John Deere 726 / 826 / 832 / 1032 Snowblower
• MTD / Craftsman Two-Stage Snow Thrower
• Cub Cadet / Toro Snowblower Models
PRODUCT NOTICE:
As a parts distributor we mostly sell aftermarket parts (any OEM parts would be noted as such). Aftermarket parts are not sourced from the original vehicle or equipment manufacturer, but are designed to function the same as - if not better than - the original. All parts sold are new.
WARNING - This product may expose you to chemicals which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
