OEM PART NUMBERS:
• WS7F / 7545 / 0241235567
• Carlton: SPCA8
• GB: WS7F
• Cross Ref: 77-300-1 / 77-311 / 77-311-1 / 268-5680 / B17812 / 17200 BX WS7F
SPECIFICATIONS:
• Type: Standard Spark Plug (Non-Resistor)
• Thread Diameter: 14mm | Thread Pitch: 1.25mm
• Reach: 9.5mm (3/8") | Hex Size: 3/4" (19mm)
• Gap: 0.020" (0.5mm)
• Seat Type: Gasket | Terminal: Removable Nut
• Center Electrode: Nickel, 2.5mm, Projected, Yttrium-Enhanced Copper Core
• Ground Electrode: Nickel Chromium, Cut Back
• Heat Range: 7
• Torque: Cast Iron 15-18 lb-ft / Aluminum 11-15 lb-ft (or 90° angle)
• Packaging: OEM Package | Quantity: Pack of 10
• Condition: New
APPLICATIONS:
• Fits Jonsered 820 / 840 | Echo CS-300 / CS-301 / CS-341 / CS-346 / CS-520
• Fits Echo CS-3000 / CS-3400 / CS-4400 / CS-5000 / CS-6700
• Fits Husqvarna 340 / 345 / 351 / 353 | Stihl 017 / 018 / MS170 / MS180
• 2-Stroke: Chainsaws, Trimmers, Blowers, Brushcutters
