5/8" X 104" Mower Deck Drive Belt Compatible With X330 X350 X370 X380 X390 X570 X580 X590 48A Deck

OEM PART NUMBERS:
• John Deere: M119685 / M169500
• Kubota: 70000-74015 / 76589-61660
• Dixie Chopper: 2008B101R / 30239-0
• Dayco: L5104
• Gates: 69104
• Goodyear: 851040
• Reference: B101 / 5L1040

SPECIFICATIONS:
• Belt Type: B/5L Section V-Belt
• Outside Circumference: 104" (2,641mm)
• Inside Circumference: 101" (2,565mm)
• Top Width: 5/8" (15.88mm)
• Depth: 7/16" (11.11mm)
• Construction: 2-Ply Neoprene Cover
• Cord Material: Aramid (Kevlar)
• Resistance: Oil and Heat Resistant
• Cut Resistance: High
• Anti-Stretch Properties
• Condition: New

APPLICATION:
• John Deere X330-X394/X570-X590 48A Accel Deep Deck
• John Deere 316/318/322/330/332/425/445/455 48" Deck
• Kubota T1700HX w/ RC48LT-17 48" Mower
• Dixie Chopper 2044/2344 Iron Eagle (2008-2013)
• Dixie Chopper 2244HP Magnum/3374/4074 XCaliber (2014-2017)
• Fits Various Applications by Part Number

48A Mower Deck Drive Belt — Direct OEM Replacement
Aramid cord reinforced V-belt built for mower deck drive systems on John Deere X-series and 300-series garden tractors, Kubota T1700HX, and Dixie Chopper zero-turn mowers. Two-ply neoprene cover delivers excellent resistance to oil, heat, and abrasion. Replaces John Deere M119685/M169500, Kubota 70000-74015/76589-61660, and Dixie Chopper 2008B101R/30239-0. Verify your original part number before ordering.

PRODUCT NOTICE:
As a parts distributor we mostly sell aftermarket parts (any OEM parts would be noted as such). Aftermarket parts are not sourced from the original vehicle or equipment manufacturer, but are designed to function the same as - if not better than - the original. All parts sold are new.
