New 16/2 Awg Marine Duplex Cable 100Ft Tinned Copper 2-Conductor Red Black Gray Jacket Compatible

UNIVERSAL MARINE WIRE — 16/2 AWG ROUND DUPLEX GRAY JACKET BOAT CABLE 100 FT SPOOL:

GRAY-JACKETED MARINE CABLE — OEM SPEC AND DIFFERENTIATION APPLICATIONS:
This is the gray-jacketed variant of Cobra's 16/2 marine duplex low-current accessory cable. The gray outer jacket provides circuit differentiation from standard white-jacketed DC cables and matches OEM boat builder harness color specifications on certain vessels. Internal conductors meet SAE J1128 / ABYC E-11 with traditional red positive + black DC negative color coding. 16 AWG is the smallest practical gauge for marine accessory wiring.

CABLE CONFIGURATION:
• 2 Conductors x 16 AWG Each (Red + Black per SAE J1128 / ABYC E-11)
• GRAY Round Outer PVC Jacket — Differentiation From Standard White Marine Cable
• Class K Type 3 Tinned-Copper Stranding (26 x 30, Marine Spec)
• 600V Voltage Rating
• 105°C Dry / 75°C Wet Temperature Rating
• Standard Rating: 10A Continuous Low-Current Branch
• Maximum Amperage: 18A Outside Engine Spaces / 14A Inside Engine Spaces
• UL Listed BC-5W2 Boat Cable per UL 1426
• 100 Foot Spool

WHY CHOOSE GRAY JACKET vs STANDARD WHITE:
• OEM Boat Builder Harness Color Match (Specific Vessels Use Gray)
• Circuit Differentiation in Installations With Multiple Cable Types
• Industrial and Commercial Marine Applications Where Gray is Preferred
• Visible Cable Run Aesthetics — Gray Often Desired for Visible Installations
• Match Existing Harness Color for Repair and Extension Work
• Differentiation From Standard White DC Cable in Engine Rooms / Service Areas

ABYC E-11 DC COLOR CODE — RED + BLACK INNER CONDUCTORS:
Inner conductors follow ABYC E-11 / SAE J1128 standards:
• RED = Positive 12V Ungrounded Conductor
• BLACK = Traditional DC Negative / Ground Return Conductor
Black remains acceptable per current ABYC standards (yellow has been preferred since the 2008 revision for new construction).

WHEN TO USE 16/2 — LOW-CURRENT BRANCH CIRCUITS (~10A):
• 16/2 THIS ITEM (~10A) = LOW-CURRENT accessories, small pumps, indicator lights
• 14/2 (~15A) = standard branch circuits, most pleasure boat accessories
• 12/2 (~25A standard) = distribution feeds, larger pumps, amp power
• 10/2 (~30-40A) = subpanel feeds, smaller inverters

COMMON 16/2 GRAY JACKET MARINE APPLICATIONS:
• OEM Boat Builder Cable Replacement (Vessels Originally Wired with Gray)
• Smaller Bilge Pump Runs (500-800 GPH Pumps)
• Cabin Lighting Circuits (Low-Power LED)
• Compass Light Wiring
• Switch Indicator Light Circuits
• Smaller Fishfinder / Electronics Power Feeds
• Cigarette Lighter / 12V Outlet Circuits (Light-Duty)
• Trim Tab Indicator Wiring
• Engine Alarm and Buzzer Wire
• Tachometer and Gauge Backlighting
• Battery Monitor Wiring
• Switch and Sensor Wiring
• Marine Intercom Power
• Smaller Wakeboard Tower Lights
• Small Horn Power
• Small Anchor Light Wiring
• Stern Light Wiring
• Cockpit Reading Lights
• Marine Clock Power
• Engine Room Work Light
• Small Spotlight Wiring
• Marine Gauge Backlighting
• Bow Light Wiring (Smaller Units)
• Accent and Mood Lighting Circuits
• Small Cabin Fan Power
• Shower Sump Pump Wiring
• Small Aerator Pump Wiring
• Switch Panel Indicator LEDs
• Low-Current Sensor Power Lines
• Industrial Marine Low-Current Branches
• Commercial Vessel Indicator Wiring
• Engine Room Service Wiring (Differentiated from White)

NOT RECOMMENDED FOR (USE LARGER GAUGE OR DIFFERENT CABLE):
• Standard Bilge Pumps (800-1100 GPH) — Use 14/2 (B6G14T-21)
• Distribution Panel Feeds — Use 12/2 (B6G12T-21) or Larger
• Inverter Inputs — Use 10/2 (B6G10T-21) or 8/2
• Loads Above ~10 Amps Continuous — Step Up to 14/2
• Trolling Motors — Use 10/2 or 8/2 Dedicated
• Main Battery Cables — Use Heavy Gauge Single-Conductor
• AC Circuits — Use AC Triplex Cable (Black/White/Green)
• Bonding/Safety Ground — Use Single-Conductor Green Wire

COMPATIBLE VESSEL TYPES:
• All Powerboats — Center Console, Cuddy Cabin, Express Cruiser, Walk-Around
• All Sailboats — Day Sailers, Cruisers, Racing Yachts
• Pontoon Boats and Houseboats
• Bass Boats and Bay Boats
• OEM Boats Originally Wired with Gray-Jacketed Cable
• Industrial and Commercial Marine Vessels
• Personal Watercraft (PWC) Wiring Harness Repairs
• Sterndrive and Inboard Engine Compartment Wiring
• RV and Trailer Marine-Grade Low-Current Accessory Wiring

STANDARDS COMPLIANCE:
• UL Listed UL 1426 Boat Cable Standard
• UL Listed BC-5W2 Boat Cable Classification
• ABYC E-11 Compliant (American Boat & Yacht Council)
• Inner conductors meet SAE J1128
• United States Coast Guard (USCG) Approved
• Made in USA

FITMENT NOTE:
Universal multi-conductor round duplex marine cable with GRAY jacket — fits any marine application requiring 16/2 AWG paired DC conductors with gray outer jacket for OEM spec match or circuit differentiation. Not vehicle-specific. Per ABYC E-11, red is positive 12V and black is the traditional DC negative. Inner conductors are identical to standard white-jacketed cable — only the outer jacket color differs. For standard white jacket use B6W series. For higher current step up to 14/2 (B6G14T-21 gray); to 12/2 (B6G12T-21); to 10/2 (B6G10T-21).
