Powerhead Rebuild Kit Compatible With 2000-2015 Yamaha 150 175 200 Hp Hpdi 2.6L V6 3.554 Bore

OEM PART NUMBERS (YAMAHA):
• Yamaha: 68F-11642-00-85 / 68F1164200-85 (Port Piston, .010 Over base)
• Yamaha: 68F-11631-00-85 / 68F1163100-85 (Starboard Piston, .010 Over base)
• Yamaha: 68F-W0001-01-00 / 68FW00010100 (Powerhead Gasket Kit)
• Yamaha: 93311-940U3-00 / 93311940U300 (Upper Main Bearing)
• Yamaha: 93310-954U1-00 / 93310954U100 (Center Main Bearing)
• Yamaha: 93310-954V3-00 / 93310954V300 (Center Main Bearing)
• Yamaha: 93310-32337-00 / 9331032337-00 (Top End Needle Bearing)
• Yamaha: 93310-836U0-00 / 93310836U000 (Lower Rod Bearing)
• Yamaha: 90109-08022-00 / 9010908022-00 (Rod Bolt)

SPECIFICATIONS:
• Product: Powerhead Rebuild Kit (.010 Over)
• Bore: 3.554" (90.25mm) | Stroke: 2.677" (68.0mm)
• Engine: Yamaha 2596cc (2.6L) V6 76° 2-Stroke HPDI
• Kit: 6 Pistons, Rings, Pins, Gaskets, Bearings, Rod Bolts

YAMAHA HPDI 2.6L V6 OUTBOARD APPLICATIONS:
• Z150/LZ150/VZ150 HPDI 150HP 2.6L V6 (2000-2015)
• Z175/VZ175 HPDI 175HP 2.6L V6 (2001-2013)
• Z200/LZ200/VZ200 HPDI 200HP 2.6L V6 (2000-2013)

PRODUCT NOTICE:
As a parts distributor we mostly sell aftermarket parts (any OEM parts would be noted as such). Aftermarket parts are not sourced from the original vehicle or equipment manufacturer, but are designed to function the same as - if not better than - the original. All parts sold are new.

WARNING - This product may expose you to chemicals which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
