PRODUCT TYPE: TURBOCHARGER
SPECIFICATIONS:
MODEL: GARRETT GT3782VA
CONDITION: NEW
TYPE: TURBOCHARGER, VARIABLE GEOMETRY (VGT)
TECHNOLOGY: ADVANCED VARIABLE NOZZLE TURBINE (AVNT™)
ACTUATION: INCLUDES VGT CONTROL VALVE / SOLENOID
ENGINE FITMENT: FORD POWER STROKE 6.0L, NAVISTAR VT365
COMPRESSOR WHEEL INDUCER: 56.8MM
COMPRESSOR WHEEL EXDUCER: 82MM
TURBINE WHEEL BLADES: 13
TURBINE WHEEL INDUCER: 72.7MM
TURBINE WHEEL EXDUCER: 64MM
DESIGN IMPROVEMENTS: INCLUDES UPDATED CENTER HOUSING WITH A MACHINED RECESS TO PREVENT CORROSION AND STICKING OF THE UNISON RING, IMPROVED VANE DESIGN WITH ENHANCED METALLURGY, AND STRICTER CONTROL PARAMETERS ON THE SOLENOID CONTROL VALVE TO REDUCE OIL LEAKAGE.
REPLACES:
OEM: FORD, NAVISTAR/INTERNATIONAL
OEM INTERCHANGE PART NUMBERS: 100TBC512S 100TBC523 100TBC523S 1700250109 1700251180 170-025-0109 170-025-1180 1832255C91 1832255C92 1854593C91 1858116C91 1876493C91 1877834C91 1877834C92 1879413C91 1879413C92 2T206 4C3Z6K682AARM 4C3Z6K682ARM 4C3Z6K682BA 4C3Z6K682CBRM 4C3Z6K682CCRM 4C3Z6K682CDRM 5010147R93 5010399R91 5010422R91 5C3Z6K682A 5C3Z6K682AA 5C3Z6K682BA 5C3Z6K682CA 5C3Z6K682CARM 5C3Z6K682CC 5C3Z6K682CCRM 5C3Z6K682DA 5C3Z6K682DARM 5C3Z9T428AA 5C3Z9T428CARM 725390-5006S 734852-5009S 743250-0016 743250-0025 743250-5014 743250-5014S 743250-5024S 743250-5025 743250-5025S 743250-9014 743250-9025S 772441-5001S 777469-5001S AP90002 TC17RM
PRODUCT NOTICE:
As a parts distributor we mostly sell aftermarket parts (any OEM parts would be noted as such). Aftermarket parts are not sourced from the original vehicle or equipment manufacturer, but are designed to function the same as - if not better than - the original. All parts sold are new.
