New 10/2 Awg Marine Flat Cable 100Ft Tinned Copper 2-Conductor Red Yellow Compatible With Marine

UNIVERSAL MARINE WIRE — 10/2 AWG FLAT DUPLEX BOAT CABLE 100 FT SPOOL:

CABLE CONFIGURATION:
• 2 Conductors x 10 AWG Each (Red + Yellow Modern ABYC E-11 DC Pair)
• White FLAT Outer PVC Jacket — Low-Profile Duplex Construction
• Class K Tinned-Copper Stranding
• 600 Volt Rated for Marine DC Distribution Use
• 105°C Dry / 75°C Wet Temperature Rating
• UL Listed BC-5W2 Boat Cable per UL 1426
• ABYC E-11, USCG Approved, Made in USA

ABYC E-11 MODERN DC COLOR CODE — RED + YELLOW PAIR:
Per the 2008 ABYC E-11 revision, YELLOW is the PREFERRED color for DC negative conductors in new construction (replacing black as the preferred designation). RED remains the standard for positive 12V conductors. This 10/2 flat duplex provides the modern ABYC-preferred color pair in a single jacketed cable.
• RED = Positive 12V Ungrounded Conductor
• YELLOW = Modern Preferred DC Negative (Per 2008 ABYC E-11 Revision)

FLAT DUPLEX vs ROUND MULTI-CONDUCTOR — WHEN TO USE FLAT:
• Low-Profile Cable Lays Flat Against Bulkheads and Stringers
• Cleaner Installation Appearance for Visible Cable Runs
• Easier to Route Along Frames with Marine Staples
• Less Protrusion Under Flooring and Carpeting
• Better for Tight Stringer Channels
• Easier to Pass Under Cable Raceways
• Round cable (B6W series) is preferred when running through conduit or loom

MODERN ABYC PAIR vs TRADITIONAL — WHICH TO CHOOSE:
• Red + Yellow (this cable) = MODERN ABYC E-11 (preferred for new construction since 2008)
• Red + Black (B6W16T-21 16/2 round) = Traditional ABYC (still acceptable, common in older boats)
Both are ABYC compliant. Yellow is preferred for new builds and modern surveys; black is acceptable for matching existing harnesses and traditional restorations.

COMMON 10/2 FLAT DUPLEX MARINE DC APPLICATIONS:
• 30 Amp DC Distribution Panel Main Feed
• Battery to Subpanel Distribution Run
• Larger Bilge Pump Dedicated Cable (1500-2000+ GPH Pumps)
• Macerator Pump Dedicated Power Cable
• Smaller Windlass / Anchor Winch Power Cable
• Trolling Motor Dedicated Run (12V Medium-Power Systems)
• Inverter Input Cable (500-1000W Marine Inverters)
• Battery Charger Output (10-30A Smart Chargers)
• Solar Charge Controller Output (Medium Solar Arrays)
• Marine Refrigerator Dedicated Feed (Medium Units)
• Cabin Heater Power Cable (Smaller Units)
• Stereo Amplifier Dedicated Power Cable (300-500W)
• High-Power LED Spotlight and Searchlight Cable
• Trim Tab Pump Dedicated Power
• Bait Tank Pump Power (Larger Pumps)
• Marine Air Conditioning DC Feed (Smaller Units)
• Watermaker Power Cable (Smaller Watermakers)
• Subpanel Feed in Mid-Size Vessels
• Engine Cooling Fan Power Cable

NOT RECOMMENDED FOR (USE LARGER GAUGE OR DIFFERENT CABLE):
• Main Battery Cables — Use Heavy Gauge Single-Conductor (8, 4, 2, 1/0 AWG)
• Engine Starter Wiring — Use Heavy Gauge Single-Conductor
• Large Inverters (1500W+) — Use 8/2 or 6/2 Cable
• Large Bow Thrusters — Use 8 AWG, 4 AWG, or 2 AWG Single-Conductor
• High-Current Loads Above ~40 Amps Continuous — Step Up to 8/2
• AC Circuits — Use AC Triplex Cable (Black/White/Green)
• Bonding/Safety Ground — Use Single-Conductor Green Wire

COMPATIBLE VESSEL TYPES:
• All Powerboats — Center Console, Cuddy Cabin, Express Cruiser, Walk-Around
• All Sailboats — Day Sailers, Cruisers, Racing Yachts, Liveaboards
• Pontoon Boats and Houseboats with Medium DC Distribution
• Bass Boats with Medium-Power Trolling Motor Runs
• Modern New Construction Following 2008 ABYC E-11 Color Code
• Sterndrive and Inboard Engine Compartment DC Distribution
• RV and Trailer Marine-Grade Medium-Current DC Wiring

STANDARDS COMPLIANCE:
• UL Listed UL 1426 Boat Cable Standard
• UL Listed BC-5W2 Boat Cable Classification
• ABYC E-11 Compliant — 2008 Revision (Modern Color Code)
• United States Coast Guard (USCG) Approved
• Made in USA

FITMENT NOTE:
Universal multi-conductor flat duplex marine cable — fits any DC marine application requiring 10/2 AWG paired modern ABYC-preferred conductors. Not vehicle-specific. Per 2008 ABYC E-11, yellow is the modern preferred DC negative color (red is positive). For round profile use B6W series. For larger AC current applications use AC triplex (black/white/green). For traditional black DC negative pair use B6W16T-21 or use single-conductor wire.
