OEM PART NUMBERS:
• Yamaha: 1XD-F518F-00-00 / 1XDF518F0000
• Yamaha: 1XD-F518F-01-00 / 1XDF518F0100
SPECIFICATIONS:
• Axle Position: Front Right or Left (Interchangeable)
• Shaft Type: CV (Constant Velocity) Double Offset Joint
• Inboard Splines: 21 Teeth
• Outboard Splines: 27 Teeth
• Compressed Length: 737 mm (29.0")
• Shaft Diameter: 13/16" (21mm)
• Thread Size: M24 x 1.5
• Material: 4140 Chromoly Steel
• Condition: New
YAMAHA UTV APPLICATIONS:
• Viking 700 EPS 686cc Liquid-Cooled SOHC 4-Valve Single-Cyl 4-Stroke (2014-2025)
• Viking VI 700 (2015-2025)
• Wolverine 700 (2016-2018)
• Wolverine R-Spec (2016-2018)
PRODUCT NOTICE:
As a parts distributor we mostly sell aftermarket parts (any OEM parts would be noted as such). Aftermarket parts are not sourced from the original vehicle or equipment manufacturer, but are designed to function the same as - if not better than - the original. All parts sold are new.
