Tilt Trim Motor And Reservoir Compatible With 1986-1991 Force 85 90 120 125 135 150 Hp Volvo Penta

OEM PART NUMBERS:
• Force: 820545
• Force: F694541-1 / F6945411
• Force: F694541-2 / F6945412
• ARCO Marine: 6212
• API Marine: PT116N-3
• Sierra: 18-6279

SPECIFICATIONS:
• Unit Type: Tilt Trim Motor with Reservoir
• Voltage: 12V
• Field Housing OD: 74.7mm / 2.941in
• Overall Length: 175.1mm / 6.894in
• Shaft OD: 8.2mm / 0.323in
• Wire Connection: 2-Wire
• Approximate Weight: 4.26 lbs / 1.94 kg
• Condition: New

APPLICATION:
• Force Outboard 85/90/120/125/135/150HP (1986-1991)
• Volvo Penta Outboard 85/90/120/125/135/150HP (1986-1991)
• All models with 2-wire tilt trim connection (1986-1991)

12V Tilt Trim Motor - Force and Volvo Penta Outboard 85-150HP
New 12 volt tilt trim motor and reservoir assembly for 1986-1991 Force and Volvo Penta outboard motors ranging from 85 to 150 horsepower. Features 2-wire connection and integrated hydraulic reservoir. Direct OEM replacement for Force 820545, F694541-1, F694541-2, ARCO Marine 6212, API Marine PT116N-3, and Sierra 18-6279. Field housing measures 74.7mm OD with 8.2mm shaft diameter and 175.1mm overall length. Weighs approximately 4.26 lbs.
