OEM PART NUMBERS:
• Mercury Marine: 50-44369A1 / 5044369A1
• Mercury Marine: 50-44369 / 5044369 (Superseded)
• Johnson Electric: 4820340 / 4820340-M030SM
• Johnson Electric: SM47764
• Johnson Electric: SM48203
SPECIFICATIONS:
• Type: PMDD (Permanent Magnet Direct Drive)
• Voltage: 12V
• Rotation: Counterclockwise (CCW)
• Tooth Count: 10
• Gear OD: 32.1mm / 1.264"
• Field Case Length: 4.118" / 104.6mm
• Mounting: (1) 4.5mm Hole on Triangular Ear
• Mounting: (1) 1/4-20 Threaded Hole on Side of Drive Cap
• Weight: 6.065 lbs / 2.76 kg
• SAE J1171 Marine Ignition Protection Certified
• Condition: New
MERCURY & MARINER OUTBOARD APPLICATIONS:
• Mercury 50HP 3-Cyl 2-Stroke: 50ELO, 50ELPTO, 50ELHPTO, 50EO (1986-1997)
• Mercury 60HP 3-Cyl 2-Stroke: 60E, 60EL, 60ELO, 60ELPT, 60ELPTO, 60ELHPTO, 60EO (1984-1997)
• Mercury 60HP Big Foot 3-Cyl 2-Stroke: 60ELPTO Big Foot (1995-1997)
• Mercury 60HP Jet: 60EO Jet 45 (1994-1997)
• Mariner 50HP 3-Cyl 2-Stroke: 50ELO, 50ELPTO, 50ELHPTO, 50EO (1986-1997)
• Mariner 60HP 3-Cyl 2-Stroke: 60EL, 60ELO, 60ELPT, 60ELPTO, 60ELHPTO, 60EO (1984-1997)
• Mariner 60HP Big Foot / Jet 45 (1995-1997)
AFTERMARKET CROSS REFERENCE:
• Arco Marine: 5388
• Sierra: 18-5606
PRODUCT NOTICE:
As a parts distributor we mostly sell aftermarket parts (any OEM parts would be noted as such). Aftermarket parts are not sourced from the original vehicle or equipment manufacturer, but are designed to function the same as - if not better than - the original. All parts sold are new.
WARNING - This product may expose you to chemicals such as Lead, Carbon Black, Silica, Crystalline which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
