OEM PART NUMBERS:
• John Deere: AT254905 / AT195649
• Isuzu: 8970489681 / 8972251170
• Denso: 100211-4710 / 1002114710 / TN100211-4710
• Denso: 100211-4711 / 1002114711 / TN100211-4711
• Denso: 0210800830 / 1012111240
• Lucas: LRA01910 / LRA1910
SPECIFICATIONS:
• Type: Alternator (Isuzu/Denso Style)
• Voltage: 12V / Amperage: 35A
• Pulley: Single V-Groove / 69mm OD
• Fan: Dual Internal
• Regulator: Internal (12:00 Position)
• Polarity: Negative Ground
• Output Stud: M6-1.0
• Top DE Mounting Ear: M8-1.25 Threaded
• Bottom Mounting Ear: 10.3mm Unthreaded
• Connector: 3-Blade Plug
• Weight: 6.6 lbs / 3.00 kg
• Condition: New
JOHN DEERE ZTS EXCAVATOR APPLICATIONS:
• 27 ZTS — Isuzu 3LD1 3-Cyl 1.5L 22HP (to S/N #220207)
• 35 ZTS — Isuzu 3LD1 3-Cyl 1.5L 29HP (to S/N #230253)
• 50 ZTS — Isuzu 4LE1 4-Cyl 2.2L 38HP (to S/N #240093)
HITACHI EXCAVATOR APPLICATIONS:
• EX27U / EX27UNA / EX30U / EX35U / EX40U — Isuzu 3LD1 Diesel
• EX50U / EG30 — Isuzu 4LE1 / Diesel
ISUZU ENGINE COVERAGE:
• 3LA1 / 3LB1 (1991+) / 3LD1 / 3LD2 (1992+)
• 4LB1 / 4LC1 / 4LE1 / 4LE2 (1993+)
PRODUCT NOTICE:
As a parts distributor we mostly sell aftermarket parts (any OEM parts would be noted as such). Aftermarket parts are not sourced from the original vehicle or equipment manufacturer, but are designed to function the same as - if not better than - the original. All parts sold are new.
WARNING - This product may expose you to chemicals such as Lead, Carbon Black, Silica, Crystalline which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
