CHEVROLET / GMC:
• Chevrolet / GMC medium and heavy-duty trucks, all models by engine, Caterpillar 3116 diesel 1990-2002
• Chevrolet / GMC Topkick / Kodiak with Caterpillar 3116 1990-2002; with Caterpillar C7 1997-2002
• Chevrolet / GMC B7 with Caterpillar 3116 1993-1998; with Caterpillar 3126 1993-1998
• Chevrolet / GMC C50, C5500, C60, C70, C80, C8500 with Caterpillar 3116 1990-2000
• Chevrolet / GMC C6500, C7500 with Caterpillar 3116 1990-2002
• Chevrolet / GMC P-Series trucks and van chassis with Caterpillar 3116 1990-2000
• Chevrolet / GMC T5500, T6500, T7500, T8500 with Caterpillar 3116 1997-1998
CHEVROLET:
• Chevrolet B7 with L6 6.6L 403 cid Caterpillar 3116 1993-1998; with L6 7.2L 441 cid Caterpillar 3126 1998-2002
• Chevrolet C4500 Kodiak, C5500 Kodiak with Caterpillar 3126 1998-2002
• Chevrolet C60 Kodiak, C70 Kodiak with L6 6.6L Caterpillar 3116 1990-1996
• Chevrolet C6500 Kodiak, C7500 Kodiak with 6.6L Caterpillar 3116 1997-1998; with 7.2L Caterpillar 3126 1998-2003; with 7.2L Caterpillar C7 2004-2007
• Chevrolet C8500 with 7.2L Caterpillar 3126 2003-2005; with 7.2L Caterpillar C7 2004-2007
• Chevrolet P6000 with 6.6L Caterpillar 3116 1992-1996
• Chevrolet T6500, T7500 with 6.6L Caterpillar 3116 1997-1998; with 7.2L Caterpillar 3126 1998-2002
GMC:
• GMC B7 with 6.6L Caterpillar 3116 1991-1998; with 7.2L Caterpillar 3126 1998-2002
• GMC C6000 Topkick, C7000 Topkick with 6.6L Caterpillar 3116 1990-1996
• GMC C6500 Topkick with 6.6L Caterpillar 3116 1997-1998; with 7.2L Caterpillar 3126 1998-2003; with 7.2L Caterpillar C7 2004-2007
• GMC C7500 Topkick with 6.6L Caterpillar 3116 1997-1998; with 7.2L Caterpillar 3126 1998-2003 and 2005; with 7.2L Caterpillar C7 2004-2007
• GMC C8500 Topkick with 7.2L Caterpillar 3126 2003; with 7.2L Caterpillar C7 2004-2007
• GMC P6000, P6500 with 6.6L Caterpillar 3116 1992-1996
• GMC T6500, T7500 with 6.6L Caterpillar 3116 1997-1998; with 7.2L Caterpillar 3126 1998-2002
WHITE:
• White/GMC WG with 6.6L Caterpillar 3116 1991 and 1995
• White Industrial medium and heavy-duty trucks, all models by engine, Caterpillar 3116 1990-1995
SPECIFICATIONS:
• Voltage: 12
• Output: 4.6 kW
• Type: 37MT type direct drive (DD)
• Rotation: clockwise (CW)
• Pinion: 10 teeth, 8/10 pitch, 39.6 mm (1.559 in) OD
• Mount: SAE 1 three-hole flange
• Mounting holes: 10.8 mm (0.425 in) unthreaded
• Drive housing: rotatable, Delco type 10499864
• Solenoid position: 308 or 128 degrees (check against your original)
• Battery stud: 1/2 in
• Overcrank protection: no
• Weight: 53 lb / 24.09 kg
• Condition: New aftermarket
