OEM PART NUMBERS:
• Prestolite: 46-2473 / 46-2482 / 46-2584 / 46-2743 / 46-3618 / 46-3938
• Prestolite: MDL-2256 / MKW-4009 / MKW-4011
• Prestolite: MUE-6103 / MUE-6103S / MUE-6111 / MUE-61118 / MUE-6111S
• Prestolite: MUE-6206 / MUE-6206AS / MUE-7001
• Western: 50133 / 54133 / 56058 / 56062 / 56133 / 56398 / 56410 / 58058 / 58062 / 58082
• Fisher: A5819
• Fenner Stone: M4-3499-00
• Northman: 40008
• Bosch: 9130450083
• Johnson Electric: MM18896 / MM18996
• W-8994 / W-6994
SPECIFICATIONS:
• Voltage: 12V
• Rotation: CW (Clockwise)
• Power: 1.7kW / 2.28 HP
• Shaft OD: 16mm (0.626 in) Slotted
• Terminal: 5/16-24 (x2)
• Field Housing OD: 114.3mm / 4.5 in
• Overall Length: 209.3mm / 8.24 in
• Field Coils: 4
• Bearing: Single Ball Bearing
• Oil Seal at Drive End
• Mounting Plate: Included with (2) 12.9mm ID Holes
• Housing: Cast Aluminum DE / Red Painted Field Case
• Condition: New
APPLICATION:
• Fisher Snow Plow UniMount Hydraulic Pump Systems
• Western Snow Plow UniMount Hydraulic Pump Systems
• Fenner Stone / Northman Snow Plow Applications
PRODUCT NOTICE:
As a parts distributor we mostly sell aftermarket parts (any OEM parts would be noted as such). Aftermarket parts are not sourced from the original vehicle or equipment manufacturer, but are designed to function the same as - if not better than - the original. All parts sold are new.
WARNING - This product may expose you to chemicals such as Lead, Carbon Black, Silica, Crystalline which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
