OEM PART NUMBERS:
• Prestolite: MUE6306 / MUE6306S / MUE6306A / MUE6302 / MUE6302S
• Western Motor: W-6306
• Haldex-Barnes: 220-1115
SPECIFICATIONS:
• Voltage: 12V DC
• Rotation: CW (Clockwise)
• Power: 1.2kW / 1.61 HP
• Ground: Insulated (Fully Insulated)
• Field Coils: 4
• Shaft OD: 16mm (0.63 in) - Slotted
• Terminal: Dual 5/16-18 Posts (2-Terminal)
• Field Housing OD: 114.1mm / 4.492 in
• Overall Length: 179.4mm / 7.063 in
• Thru Bolts: At 3:00 and 9:00 Position
• Weight: 15.85 lbs / 7.21 kg
• Supplied Without Drive End (DE) Frame
• Condition: New
APPLICATION:
• Fisher Snow Plow Systems
• Western Snow Plow Systems
RELATED PART NUMBERS:
• 482777 - Same motor with thru bolts at 12:00 and 6:00 position
• 553343 - Same motor with bearing CE end
PRODUCT NOTICE:
As a parts distributor we mostly sell aftermarket parts (any OEM parts would be noted as such). Aftermarket parts are not sourced from the original vehicle or equipment manufacturer, but are designed to function the same as - if not better than - the original. All parts sold are new.
WARNING - This product may expose you to chemicals such as Lead, Carbon Black, Silica, Crystalline which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
