OEM PART NUMBERS:
• GM: 84666664 (current) / 84786601 / 84945489
• GM: 84666663 / 84635619 / 84635623 (superseded)
• GM: 23489592 / 23377847 / 23301206 / 23301207 (superseded)
• GM: 23287187 / 23291879 / 23249243 / 23398670 / 23106025 (earlier)
• 1522380 / 1522386 / 1522341 / 1522329 / 1522312
• CO11483C / CO-11483C
• 158275 / 197299 / 198299
• Carlisle: 3022397
SPECIFICATIONS:
• Compressor Type: CVC7 (Electronically Controlled Variable Displacement)
• Control: PWM (Pulse Width Modulation)
• Voltage: 12V
• Clutch Pulley: 5-Groove, 109mm diameter
• Refrigerant: R134a or R1234yf (dual compatible)
• Oil Type: PAG 46
• Oil Capacity: 150ml (pre-filled)
• Includes: Clutch and Coil Assembly
• Condition: New
CHEVROLET APPLICATIONS:
• Colorado WT/LT/Z71 2.5L LCV I4 200HP (2015-2022)
• Equinox L/LS/LT/Premier/RS 1.5L Turbo 170HP (2018-2023) / 2.0L Turbo 252HP (2018-2021)
GMC / BUICK APPLICATIONS:
• Canyon Base/SLE/SLT/Elevation 2.5L LCV I4 200HP (2015-2022)
• Terrain SLE/SLT/Denali 1.5L Turbo 170HP (2018-2022)
• Envision 2.5L I4 197HP (2016-2018) / 2.0L Turbo 252HP (2016-2020)
PRODUCT NOTICE:
As a parts distributor we mostly sell aftermarket parts (any OEM parts would be noted as such). Aftermarket parts are not sourced from the original vehicle or equipment manufacturer, but are designed to function the same as - if not better than - the original. All parts sold are new.
WARNING - This product may expose you to chemicals which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
