OEM PART NUMBERS:
• Honda: 38810-5J6-A01 / 388105J6A01 (assembly)
• Honda: 38810-5J6-A02 / 388105J6A02 (assembly, running change)
• Honda: 38810-5J6-A03 / 388105J6A03 (assembly, running change)
• Honda: 38810-RLV-A02 / 38810RLVA02 (compressor body, current)
• Honda: 38810-RLV-A01 / 38810RLVA01 (compressor body, superseded)
• Honda: 38900-5J6-A02 / 389005J6A02 (clutch & pulley assembly)
• Honda: 38924-5J6-A03 (clutch coil)
• CO11430C
• 68232 / 67232
SPECIFICATIONS:
• Compressor Type: A10HF20
• Voltage: 12V
• Clutch Pulley: 6-Groove, 135mm diameter
• Refrigerant: R134a
• Oil Type: PAG 100
• Drive: Belt Driven
• Includes: Clutch and Coil Assembly
• Weight: 9.70 lbs
• Dimensions: 10.5 x 9.0 x 8.5 inches
• Condition: New
HONDA PILOT APPLICATIONS (2016-2020):
• Pilot LX/EX/EX-L/Touring/Elite/Black Edition/Special Edition — 3.5L J35Y6 280HP 6AT/9AT (2016-2020)
HONDA RIDGELINE APPLICATIONS (2017-2019):
• Ridgeline RT/RTS/RTL/RTL-T/RTL-E/Sport/Black Edition — 3.5L J35Y6 280HP 6AT (2017-2019)
ACURA MDX APPLICATIONS (2014-2016):
• MDX Base/Technology/Advance — 3.5L J35Y5 290HP 6AT (2014-2016)
PRODUCT NOTICE:
As a parts distributor we mostly sell aftermarket parts (any OEM parts would be noted as such). Aftermarket parts are not sourced from the original vehicle or equipment manufacturer, but are designed to function the same as - if not better than - the original. All parts sold are new.
WARNING - This product may expose you to chemicals which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
