COLE HERSEE OEM PART NUMBERS (SOURCE):
• Cole Hersee: 24008 (Source Primary)
• Cole Hersee: 24008-BX (Source BX Variant)
• Cole Hersee: CH24008 (Extended Format)
NAVISTAR OEM PART NUMBER (SOURCE):
• Navistar: ZN24008-BX (Source)
• Navistar: ZN24008BX (No-Dash Variant)
PRESTOLITE OEM PART NUMBERS (SOURCE):
• Prestolite: 15-156 (Source)
• Prestolite: 15156 (No-Dash Variant)
• Prestolite: 15-337 (Source)
• Prestolite: 15337 (No-Dash Variant)
• Prestolite: 15-416 (Source)
• Prestolite: 15416 (No-Dash Variant)
ADDITIONAL OEM CROSS-REFERENCES (RESEARCH):
• Prestolite: SAS5402C
• Prestolite: SAW5406
• Ametek: 15-416
• Delco: 1114239
• Delco: 1114536
• Accumax: 10-CD204A / 10-CH71020
• Accurate: 7-1020
• Arco Marine: R024
• Fenner Stone: E3-1010-00
• National Stocking Number (NSN): 5945002385147
• TYC Reference: 24008-BX
• Item Reference: 24008-BX
SPECIFICATIONS:
• Product Type: Solenoid (Remote / Intermittent Duty SPST)
• Unit Type: Cole Hersee OEM Design
• Voltage: 24V DC
• Circuitry: SPST / Normally Open
• Continuous Amps: 65 A Break
• Surge Amps: 120 A Make
• Duty Cycle: Intermittent (10 sec On / 30 min Off)
• Coil Impedance: 29 Ohms
• Number of Terminals: 4
• Contact Material: Copper
• Body Material: Metal (Plated Steel)
• Mounting Style: Flat 180 (F180) / Flat Bracket
• Stud Size: (2) 5/16"-24 Threaded Studs for Battery & Motor
• Terminal Size: (2) 10-32 Threaded Terminals for Activation & Ground
• Hardware: Included and Pre-Assembled
• Quantity: 1 Unit
• Condition: New
• Country of Origin: Taiwan (TW)
• Source: OEM Cole Hersee Design
• Recommended Use: OE Replacement for Cole Hersee 24V Intermittent Duty Solenoids
• Product Fit: Direct Fit for 24V Heavy-Duty Commercial Applications
EQUIPMENT APPLICATIONS SUMMARY:
• Navistar International Heavy-Duty Commercial Trucks
• Heavy-Duty Commercial Trucks / Tractor Trailers
• Commercial Transit Buses / School Buses / Coach Buses
• Marine Vehicles / Commercial Boats
• Heavy-Duty Construction Equipment (24V)
• Agricultural Equipment (24V Electrical Systems)
• Industrial Remote-Switching Applications
• 24V Commercial Vehicle Starting / Accessory Systems
PRODUCT NOTICE:
As a parts distributor we mostly sell aftermarket parts (any OEM parts would be noted as such). Aftermarket parts are not sourced from the original vehicle or equipment manufacturer, but are designed to function the same as - if not better than - the original. All parts sold are new.
WARNING - This product may expose you to chemicals such as Carbon Black, Silica, Crystalline which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
