COLE HERSEE OEM PART NUMBERS (SOURCE):
• Cole Hersee: 24008 (Source Primary)
• Cole Hersee: 24008-BX (Source BX Variant)
• Cole Hersee: CH24008 (Extended Format)
NAVISTAR OEM PART NUMBER (SOURCE):
• Navistar: ZN24008-BX (Source)
• Navistar: ZN24008BX (No-Dash Variant)
PRESTOLITE OEM PART NUMBERS (SOURCE):
• Prestolite: 15-156 (Source)
• Prestolite: 15156 (No-Dash Variant)
• Prestolite: 15-337 (Source)
• Prestolite: 15337 (No-Dash Variant)
• Prestolite: 15-416 (Source)
• Prestolite: 15416 (No-Dash Variant)
ADDITIONAL OEM CROSS-REFERENCES (RESEARCH):
• Prestolite: SAS5402C
• Prestolite: SAW5406
• Ametek: 15-416
• Delco: 1114239
• Delco: 1114536
• Accumax: 10-CD204A / 10-CH71020
• Accurate: 7-1020
• Arco Marine: R024
• Fenner Stone: E3-1010-00
• National Stocking Number (NSN): 5945002385147
• TYC Reference: 24008-BX
• Item Reference: 24008-BX
SPECIFICATIONS:
• Product Type: Solenoid (Remote / Intermittent Duty SPST)
• Unit Type: Cole Hersee OEM Design
• Voltage: 24V DC
• Circuitry: SPST / Normally Open
• Continuous Amps: 65 A Break
• Surge Amps: 120 A Make
• Duty Cycle: Intermittent (10 sec On / 30 min Off)
• Coil Impedance: 29 Ohms
• Number of Terminals: 4
• Contact Material: Copper
• Body Material: Metal (Plated Steel)
• Mounting Style: Flat 180 (F180) / Flat Bracket
• Stud Size: (2) 5/16"-24 Threaded Studs for Battery & Motor
• Terminal Size: (2) 10-32 Threaded Terminals for Activation & Ground
• Hardware: Included and Pre-Assembled
• Quantity: 1 Unit
• Condition: New
• Country of Origin: Taiwan (TW)
• Source: OEM Cole Hersee Design
• Recommended Use: OE Replacement for Cole Hersee 24V Intermittent Duty Solenoids
• Product Fit: Direct Fit for 24V Heavy-Duty Commercial Applications
EQUIPMENT APPLICATIONS SUMMARY:
• Navistar International Heavy-Duty Commercial Trucks
• Heavy-Duty Commercial Trucks / Tractor Trailers
• Commercial Transit Buses / School Buses / Coach Buses
• Marine Vehicles / Commercial Boats
• Heavy-Duty Construction Equipment (24V)
• Agricultural Equipment (24V Electrical Systems)
• Industrial Remote-Switching Applications
• 24V Commercial Vehicle Starting / Accessory Systems
