OEM PART NUMBERS:
• 0120468146 / 0 120 468 146 / 0-120-468-146
• 6033GB3045
• KHD (Klöckner-Humboldt-Deutz): 118-1096 / 1181096
• Mercedes-Benz: A091546502 / 091546502
• Mercedes-Benz: 09-154-65-02 / A-091-546-502
• BOMAG: 332058544
• Volvo: 20482686
• Misc: 05712914R
SPECIFICATIONS:
• Type: Alternator
• Unit Type:
• Voltage: 24V
• Amperage: 80A
• Fan: External (EF)
• Regulator: Internal (IR)
• Rotation: Clockwise (CW)
• Pulley: 2-Groove Solid, 82mm / 3.228in OD
• Mount Type: Spool
• Mounting Ear 1: 10.2mm Unthreaded, 56.5mm thick
• Mounting Ear 2: 10.2mm Unthreaded, 56.5mm thick
• B+ Terminal: M8-1.25
• B- Terminal: M6-1.0
• W Terminal: M5-0.8
• D+ Terminal: M4-0.7
• Weight: 16.34 lbs / 7.43 kg
• Condition: New
APPLICATIONS SUMMARY:
• Timberjack Forestry Equipment — Various Models with KHD/Deutz, Mercedes-Benz, and Volvo Engines
• BOMAG Compaction Equipment — Various Models
• Verify fitment by OEM part number: 0120468146 / KHD 118-1096
PRODUCT NOTICE:
As a parts distributor we mostly sell aftermarket parts (any OEM parts would be noted as such). Aftermarket parts are not sourced from the original vehicle or equipment manufacturer, but are designed to function the same as - if not better than - the original. All parts sold are new.
