OEM PART NUMBERS:
• Bombardier / BRP: 515-175-438 / 515-175-565 / 861-510-400
• Bombardier (no dashes): 515175438 / 515175565 / 861510400
SPECIFICATIONS:
• Voltage: 12V
• Power: 0.6kW / 0.8 HP
• Starter Type: PMDD (Permanent Magnet Direct Drive)
• Rotation: CW (Clockwise)
• Teeth: 8
• Gear OD: 27.3mm / 1.075 in
• Overall Length: 209.5mm / 8.248 in
• Mounting Ear 1: 9.1mm Unthreaded
• Mounting Ear 2: 8.4mm Unthreaded
• Mounting Ear 3: 10.0mm x 8.8mm Slotted
• Mounting Ear Center to Center: 83.5mm / 3.287 in
• B+ Stud: M6
• Includes: Mounting Bolts, Solenoid, and Wiring Harness
• Weight: 5.76 lbs / 2.62 kg
• OEM Manufacturer: Denso
• Condition: New
APPLICATION:
• Lynx Super Touring 500/600 (2001)
• Ski-Doo Formula Deluxe 500/600/700 (2000-2001)
• Ski-Doo Grand Touring 500/600/700 GS (2000-2001)
• Ski-Doo Skandic Wide Track 600 (2001-2002)
PRODUCT NOTICE:
As a parts distributor we mostly sell aftermarket parts (any OEM parts would be noted as such). Aftermarket parts are not sourced from the original vehicle or equipment manufacturer, but are designed to function the same as - if not better than - the original. All parts sold are new.
