New 12V Ccw Pmdd Starter Compatible With 2000-2005 John Deere Sabre Lt150 Lt160 1948 2148 2354 Lawn

(0) Reviews: Write first review
5802NA5
OEM CROSS-REFERENCE PART NUMBERS — JOHN DEERE:
• John Deere: AM130407
• John Deere: AM132818
• John Deere: AM120729
• John Deere: AM122435
• John Deere: AM130724

OEM CROSS-REFERENCE PART NUMBERS — KOHLER:
• Kohler: 25-098-03 / 2509803
• Kohler: 25-098-04 / 2509804
• Kohler: 25-098-05 / 2509805
• Kohler: 25-098-06 / 2509806
• Kohler: 25-098-07 / 2509807
• Kohler: 25-098-07-S / 2509807S

OEM CROSS-REFERENCE PART NUMBERS — JOHNSON ELECTRIC:
• Johnson Electric: 5667140
• Johnson Electric: 6560020
• Johnson Electric: 6727040

OEM CROSS-REFERENCE PART NUMBERS — UNITED TECHNOLOGIES (UT):
• United Technologies: 6560020-M030SM / 6560020MO30SM
• United Technologies: 6727040-M030SM / 6727040MO30SM

SPECIFICATIONS:
• Product Type: Kohler Command CV Engine Starter Motor (PMDD)
• OEM Manufacturer: Johnson Electric / United Technologies (UT)
• Voltage: 12 Volt
• Rotation: Counterclockwise (CCW)
• Starter Type: PMDD (Permanent Magnet Direct Drive)
• Number of Teeth: 10
• Pinion / Gear OD: 30.77mm / 1.211"
• Field Case Length: 3.81" / 97mm
• Mounting Hole 1: 9.0mm ID Unthreaded
• Mounting Hole 2: 9.0mm ID Unthreaded
• Mounting Flanges: 50mm thick
• Battery Terminal: NOT located on field case (different from )
• Weight: 5.5 lbs / 2.50 kg
• Engine: Kohler Command CV15 / CV16 / CV20 / CV22 / CV23 (15-23HP)
• Application: John Deere LT150/LT160 + Sabre 1948/2148/2354 + Scotts S2348 (2000-2005)
• Condition: New

APPLICATION SUMMARY — JD LT/SABRE + SCOTTS WITH KOHLER CV15-CV23 2000-2005:
• 2002-2005 John Deere LT150 / LT160 with Kohler CV15 / CV16 15HP / 16HP Single-Cyl
• 2000-2002 John Deere/Sabre 1948GV / 1948HV with Kohler CV20S 19.9HP V-Twin
• 2000-2002 John Deere/Sabre 2148HV / 2354HV with Kohler CV22S / CV23S 21-23HP V-Twin
• 2000-2001 Scotts S2348 with Kohler CV23 23HP V-Twin (0.67L 674cc 41CID)

PRODUCT NOTICE:
As a parts distributor we mostly sell aftermarket parts (any OEM parts would be noted as such). Aftermarket parts are not sourced from the original vehicle or equipment manufacturer, but are designed to function the same as - if not better than - the original. All parts sold are new.

WARNING - This product may expose you to chemicals such as Lead, Carbon Black, Silica, Crystalline which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov

Was: $119.19
Sale: $68.11
Save: 43%
Save: $51.08
Qty:
Free Shipping!

Description

JOHN DEERE LT-SERIES LAWN TRACTORS — KOHLER COMMAND CV (2002-2005):
• 2002 John Deere LT150 Lawn Tractor with Kohler CV15 15HP Single-Cyl Vertical-Shaft
• 2003-2005 John Deere LT150 Lawn Tractor with Kohler CV15 15HP Single-Cyl 0.43L (426cc / 26CID) Vertical-Shaft
• 2002-2005 John Deere LT160 Lawn Tractor with Kohler CV16 16HP Single-Cyl Vertical-Shaft

JOHN DEERE / SABRE 1948 LAWN TRACTORS — KOHLER CV20 V-TWIN (2000-2002):
• 2000 John Deere/Sabre 1948GV Lawn Tractor with Kohler CV20S-65560 / CV20S-65571 19.9HP V-Twin
• 2000-2002 John Deere/Sabre 1948HV Lawn Tractor with Kohler CV20S-65560 / CV20S-65571 19.9HP V-Twin

JOHN DEERE / SABRE 2148 / 2354 LAWN TRACTORS — KOHLER CV22 / CV23 V-TWIN (2000-2002):
• 2000-2002 John Deere/Sabre 2148HV Lawn Tractor with Kohler CV22S-75529 / CV22S-75542 21HP V-Twin (48" Deck)
• 2000-2002 John Deere/Sabre 2354HV Lawn Tractor with Kohler CV23S-75531 / CV23S-75541 23HP V-Twin

SCOTTS LAWN & GARDEN TRACTOR — KOHLER 23HP V-TWIN (2000-2001):
• 2000-2001 Scotts S2348 Lawn & Garden Tractor with Scotts 2-Cyl 0.67L (674cc / 41CID) Kohler CV23 23HP V-Twin Engine

KOHLER COMMAND ENGINE FAMILY — STANDALONE APPLICATIONS:
• Kohler Command CV15 — 15HP Single-Cylinder Vertical-Shaft (LT150 application)
• Kohler Command CV16 — 16HP Single-Cylinder Vertical-Shaft (LT160 application)
• Kohler Command CV20S-65560 / CV20S-65571 — 19.9HP V-Twin Vertical-Shaft (Sabre 1948 application)
• Kohler Command CV22S-75529 / CV22S-75542 — 21HP V-Twin Vertical-Shaft (Sabre 2148 application)
• Kohler Command CV23S-75531 / CV23S-75541 — 23HP V-Twin Vertical-Shaft (Sabre 2354 / Scotts S2348)

CRITICAL DIFFERENTIATION FROM:
• (this starter): 9.0mm mounting holes, 50mm flange thickness, 5.5 lbs weight, NO battery terminal on field case
• (separate starter): 8.0mm mounting holes, 53mm flange thickness, 7 lbs weight, HAS battery terminal on field case
• Both and are 12V CCW PMDD 10-tooth starters with very similar specs and overlapping applications
• They are NOT interchangeable due to the mounting hole diameter difference (9.0mm vs 8.0mm)
• Buyers must verify the mounting hole diameter on their original starter before ordering

FITMENT NOTES — CRITICAL APPLICATION REQUIREMENTS:
• 12 VOLT SYSTEM REQUIRED
• Counterclockwise (CCW) rotation, 10-tooth pinion, 1.211" (30.77mm) gear OD
• PMDD (Permanent Magnet Direct Drive) starter — original Johnson Electric / UT design
• Field case length: 3.81" / 97mm
• Mounting: 2 ears (both 9.0mm ID unthreaded) with 50mm thick mounting flanges
• Weight: 5.5 lbs (2.50 kg)
• OEM Manufacturer: Johnson Electric / United Technologies
• Will NOT fit applications using starter (different 8.0mm mounting holes)
• Will NOT fit John Deere STX30 / STX38 / STX46 (those use with 8.0mm mounting holes)
• Will NOT fit Kohler K-Series K-161/K-181 cast-iron L-head engines (those use )
• Will NOT fit Kohler M-Series Magnum M-8 thru M-16 engines (those use )
• Will NOT fit Kohler Courage SV-Series engines (different starter family)
• Will NOT fit John Deere D100/D110/D120/D130/D140/D150/D160/D170 (different engine/starter)
• Will NOT fit John Deere LA105/LA115/LA125/LA135/LA145/LA155/LA165/LA175 (different engine/starter)
• Will NOT fit John Deere X300/X310/X324/X340 (different engine/starter)
• Always verify your OEM part number AND mounting hole diameter from the original starter before ordering
