OEM PART NUMBERS:
• Delco: 8200571, 8200196, 8300064, 8200796
• Cummins: 4996706
• Denso: 428000-7090, 438000-3110
• Freightliner: 2132-8200571 / 21328200571
SPECIFICATIONS:
• Family: Delco 29MT, Type 500
• Voltage: 12V
• Type: PLGR (Planetary Gear Reduction)
• Rotation: CW (Clockwise)
• Tooth Count: 10
• Gear OD: 40mm / 1.575in
• Power: 2.9kW / 3.89HP
• Length: 306mm / 12.047in
• Solenoid Position: 315 Degrees
• Mounting: SAE 1, 3 Ears, 11.0mm Unthreaded
• Mounting Ear Center to Center: 89mm / 3.504in
• Registry OD: 89mm / 3.504in
• Wet Clutch Seal: Yes
• Includes Control Relay
• Weight: 19.12 lbs / 8.69 kg
• Condition: New
APPLICATION:
• Freightliner 108SD/114SD/M2 100/M2 106/M2 112/MT45/MT55 w/ Cummins ISB 6.7L (2007-2018)
• Freightliner B2/S2/S2RV/MB-65/MBC/XBA-XCS Chassis w/ Cummins ISB 6.7L (2008-2017)
• Blue Bird / Thomas Built / Van Hool Bus w/ Cummins ISB 6.7L (2007-2015)
PRODUCT NOTICE:
As a parts distributor we mostly sell aftermarket parts (any OEM parts would be noted as such). Aftermarket parts are not sourced from the original vehicle or equipment manufacturer, but are designed to function the same as - if not better than - the original. All parts sold are new.
