Starter Motor Compatible With 1996-2003 Bluebird Bus Cat 3116 3126 Thomas Built Mvp-Ef Type D

OEM PART NUMBERS:
• Denso: 428000-1610, TG428000-1610
• Denso: 228000-5850, 228000-5851, TG228000-5851
• Caterpillar: 0R9226
• Bluebird: 1454651, 1935485
• Thomas Built: 61231320
• Navistar: 2585347C91

SPECIFICATIONS:
• Voltage: 12V
• Type: OSGR (Off Set Gear Reduction)
• Power: 4 kW / 5.36 HP
• Rotation: CW (Clockwise)
• Tooth Count: 10
• Gear OD: 40.3mm / 1.587in
• Mounting Ear 1: 11.6mm ID Unthreaded
• Mounting Ear 2: 11.6mm ID Unthreaded
• B+ and Ground Studs: M12-1.75
• Motor Stud: M10
• S Terminal: M5 Threaded
• Registry OD: 88.8mm
• Weight: 24.11 lbs / 10.96 kg
• Condition: New

APPLICATION:
• Bluebird Bus Cat 3116 (1996-2003), Cat 3126 (1996-2003), Cat C7 7.2L (2004-2006)
• Thomas Built MVP-EF Cat 3126, TL960 Cat 3116
• Thomas Built Type D Saf-T-Liner EF/ER/HDX Cat 3126

12V OSGR Starter — Bluebird Bus Cat 3116 3126 C7 Thomas Built Saf-T-Liner
Off set gear reduction starter for Bluebird and Thomas Built bus applications. This 12-volt unit produces 4 kW with clockwise rotation and a 10-tooth pinion. Fits Bluebird buses with Caterpillar 3116 from 1996-2003, Cat 3126 from 1996-2003, and Cat C7 7.2L from 2004-2006. Also compatible with Thomas Built MVP-EF with Cat 3126, TL960 with Cat 3116, and Saf-T-Liner Type D EF/ER/HDX with Cat 3126. The OSGR design delivers higher cranking torque with reduced current draw. Replaces Denso TG428000-1610 and Caterpillar 0R9226.
