BOSCH PART NUMBERS: • 0 001 364 301, 0001364301
• 0 001 364 100, 0001364100
• 0 986 012 700, 0986012700
• 0 001 368 001, 0001368001
• 0 001 360 035, 0001360035
DEUTZ / KHD PART NUMBERS: • 01164995, 116-4995, 1164995
• 01163626, 116-3626, 1163626
• 01179586, 117-9586, 1179586
• B17R24X4
LIEBHERR PART NUMBERS: • 6200662, 620-06-62
MAHLE / LETRIKA (ISKRA) PART NUMBERS: • MS386, MS 386
• IS0491, IS 0491
• AZJ3518
• 72736014
OTHER PART NUMBERS: • Volvo 6209190
• DAF 1516768R
• Prestolite 859539
• Poclain E0041565
• Hella 8EA 726 149-001, 8EA726149001
• Faun 1701065
SPECIFICATIONS: • Type: Bosch 368 series direct drive (DD)
• Voltage: 24 Volt
• Power: 4.0 kW
• Rotation: Clockwise (CW)
• Pinion: 9 teeth, 34.1 mm (1.343 in) OD, module 3
• Flange: 89 mm
• Mounting: 3 holes, 11 mm unthreaded, 90 / 90 / 127 mm spacing
• Pinion rest position: 28 mm
• Battery terminal: M10
• Weight: 31.7 lb (14.4 kg)
• Condition: New
PRODUCT NOTICE:
As a parts distributor we mostly sell aftermarket parts (any OEM parts would be noted as such). Aftermarket parts are not sourced from the original vehicle or equipment manufacturer, but are designed to function the same as - if not better than - the original. All parts sold are new.
