OEM PART NUMBERS (Supersession Chain):
• Yamaha: 1S3-11631-00-00 / 1S3116310000 (original)
• Yamaha: 1S3-11631-10-00 / 1S3116311000 (superseded)
• Yamaha: 2BG-11631-00-00 / 2BG116310000 (current)
• Yamaha Ring Set: 1S3-11603-10-00 / 1S3116031000
• Yamaha Wrist Pin: 5VK-11633-00-00 / 5VK116330000
SPECIFICATIONS:
• Type: Piston Kit (Standard Bore)
• Standard Bore: 102mm
• Stroke: 84mm
• Displacement: 686cc
• Compression: 9.2:1
• Piston Type: Forged Replica
• Engine: Single-Cylinder 4-Stroke SOHC 4-Valve Liquid-Cooled
• Fuel System: EFI
• Weight: 2 lbs / Condition: New
KIT CONTENTS (Single Cylinder):
• (1) Piston — Standard Bore 102mm
• (1) Ring Set / (1) Wrist Pin / (2) Circlips
• Single cylinder engine — one kit completes rebuild
APPLICATIONS:
• Yamaha Raptor 700 / 700R 686cc SOHC EFI (2006-2024)
• Yamaha Grizzly 700 686cc SOHC EFI (2007-2024)
• Yamaha Kodiak 700 686cc SOHC EFI (2016-2024)
• Yamaha Viking 700 / VI 686cc SOHC EFI (2014-2024)
• Yamaha Rhino 700 686cc SOHC EFI (2008-2013)
PRODUCT NOTICE:
As a parts distributor we mostly sell aftermarket parts (any OEM parts would be noted as such). Aftermarket parts are not sourced from the original vehicle or equipment manufacturer, but are designed to function the same as - if not better than - the original. All parts sold are new.
