OEM PART NUMBERS:
• John Deere: AR41627 / AR55639 / AR77254 / RE13722 / RE41875 / SE501414 / TY25960 / TY6617 / TY6713
• Nippondenso / 028000-3290 / 0280003290 / 028000-3291 / 0280003291 / 028000-3292 / 0280003292
• Nippondenso / 128000-0770 / 1280000770 / 128000-0771 / 1280000771 / 128000-0772 / 1280000772
• Reman: 9702800-329 / 9702800329 / 9712809-077 / 9712809077
• Hino: 28100-1670 / 281001670 / 28100-1670A / 281001670A / 28100-1671 / 281001671
• Hino: 28100-1671A / 281001671A / 28100-1672 / 281001672 / 28100-1672A / 281001672A / 28100-1672R / 281001672R
• Mercury Marine: 50-831001671 / 50831001671 / 50-831001672 / 50831001672
• Mahle: MS 365 / MS-365 / MS365
• Letrika (Iskra): IS 0663 / IS0663 / IS-0663 / AZJ3297
SPECIFICATIONS:
• Product Type: Starter Motor
• Type: DD (Direct Drive)
• Voltage: 12V
• Power: 4kW / 5.36HP
• Rotation: CW (Clockwise)
• Teeth: 10
• Gear OD: 39.8mm / 1.567"
• Housing: Rotatable DE Housing
• Mounting: 3x 10.0mm Unthreaded Ears
• OAL: 311mm (Flange to Back)
• Registry OD: 89mm
• Bolt Hole Center-to-Center: 90mm
• Weight: 46.5 lbs / 21.14 kg
• Condition: New
JOHN DEERE APPLICATIONS:
• Farm Tractors: 4030-8450 Series (1972-1990)
• Combines: 1085-9500 Series (1979-1992)
• Loaders: 444-644G Series (1975-2005)
• Excavators / Feller Bunchers / Graders / Skidders (1974-2003)
• Industrial Engines: 6059 / 6068 / 6076 / 6466A/D/T
HINO TRUCK APPLICATIONS:
• FC / FD / FE / FF / GC / LP / SF / SG Series (1984-1997)
• Engines: W06D / W06E / H06C / H07C (5.8L-6.7L)
MERCRUISER MARINE APPLICATION:
• EH700 MIE 175/220HP Hino 6.5L 6-Cyl (1986-1997)
PRODUCT NOTICE:
As a parts distributor we mostly sell aftermarket parts (any OEM parts would be noted as such). Aftermarket parts are not sourced from the original vehicle or equipment manufacturer, but are designed to function the same as - if not better than - the original. All parts sold are new.
